DIMENSIONS - C-CABINET SIZE UNIT
Figure 44.1 - Unit Dimensions (inches)
101.53
36.91
COMPRESSOR
CONTROLS
COMPARTMENT
COMPARTMENT
ACCESS DOOR
ACCESS DOOR
75.66
CONDENSING
SECTION
ACCESS PANEL
(also other side)
44
CONDENSING SECTION FAN QUANTITY:
(2) FANS FOR 15 TON UNIT
(3) FANS FOR 20 THRU 30 TON UNITS
(4) 1.50" LIFTING EYE BOLTS
(EACH CORNER OF UNIT)
64.61
4.00
APPROXIMATE AREA
FOR SIDE ELECTRIC
SERVICE ENTRANCE
70.14
(refer to Warning label
on unit for exact location)
APPROXIMATE AREA
FOR SIDE GAS
SERVICE ENTRANCE
(refer to Warning label
on unit for exact location)
GAS/ELECTRIC
HEAT (OPTION)
COMPARTMENT
ACCESS DOORS
64.28
(BASE)
60.11
SUPPLY AIR BLOWER
& EVAPORATOR/
HOT GAS REHEAT COIL
ACCESS DOOR
EVAPORATOR &
HOT GAS REHEAT COIL
SERVICE ACCESS PANEL
74.34
MCP15-500.9
107.12
ACCESSORY RAINHOOD
AND BIRDSCREEN
(FIELD INSTALLED ACCESSORY)
148.49
111.71 36.78
FILTER & DAMPERS
ACCESS DOOR
1" NPT EVAP
COIL DRAIN
PAN PIPE
CONNECTION
111.28
(BASE)
65.92
31.96
