DIMENSIONS - B-CABINET SIZE UNIT (WITH ENERGY RECOVERY)
Figure 42.1 - Unit Dimensions (inches)
85.93
31.30
6.93
71.89 64.96
CONDENSING
SECTION
ACCESS PANEL
(ALSO OTHER SIDE)
42
CONDENSING SECTION
FAN QUANTITY:
(2) FOR 7 AND 10 TON UNITS
(3) FOR 13, 15, AND 20 TON UNITS
(4) 1" LIFTING ANGLES
(EACH CORNER)
43.72
54.63
COMPRESSOR CONTROLS
COMPARTMENT COMPARTMENT
ACCESS DOOR ACCESS DOOR
APPROXIMATE AREA
FOR SIDE ELECTRICAL
SERVICE ENTRANCE
(refer to Warning label
on unit for exact location)
APPROXIMATE AREA
FOR SIDE GAS
SERVICE ENTRANCE
(refer to Warning label
on unit for exact location)
GAS/ELECTRIC
HEAT (OPTION)
COMPARTMENT
ACCESS DOORS
4.00
54.00
(BASE)
(2) 1" LIFTING ANGLES
(EACH SIDE)
168.38
SUPPLY AIR BLOWER FILTER & DAMPERS
& EVAPORATOR/ ACCESS DOOR
HOT GAS REHEAT COIL
ACCESS DOOR
EVAPORATOR & 1" NPT EVAP
HOT GAS REHEAT COIL COIL DRAIN
SERVICE ACCESS PANEL
CONNECTION
168.00
MCP15-500.9
ENERGY RECOVERY
WHEEL ECONOMIZER
BYPASS DAMPER
ACCESSORY RAINHOOD
AND BIRDSCREEN
(FIELD INSTALLED ACCESSORY)
204.30
ENERGY RECOVERY
WHEEL & CONTROLS
COMPARTMENT
ACCESS DOORS
PAN PIPE
ENERGY RECOVERY
EXHAUST AIR
RAINHOOD
32.16
EXHAUST FAN
BELT DRIVE &
AUTO BELT
TENSIONER
ACCESS PANEL
4.00
