7. Do one of the following:
• If you are in slow chop, press CHOP twice to stop toggling between the two sources.
• If you are in fast chop, press CHOP once to stop toggling between the two sources.
The status of the button returns to CHOP.

Using a Menu

The button corresponding to the current menu is always illuminated.
To use a menu:
1. Press the button that has the menu assigned to it.
2. Press the button that you want to use in that menu.
If the menu has been set up to fall back to another menu, the RCP-QE goes to the predefined menu (see
"Setting Up Menus" on page 4–13).

If you need to return to the Home menu but the RCP-QE is not responding, use DashBoard to do this. For more
information see "Returning to the Home Menu" on page 4–31.

De-Assigning a Machine Control Port

If you want to stop machine control on a particular port temporarily, you can park the port by de-assigning it.
To de-assign a machine control port:
1. Press the button for the machine control port that you want to park.
2. Press DE-ASIGN.
To unpark the machine control port:
• Make a machine control switch.

De-Assigning Resources

De-assigning resources can be done in two ways:
• Route a different source to that destination that does not require a resource. The assigned resource will
automatically be de-assigned.
• Use the de-assign button.
To-deassign a resource:
1. Select the destination to which the resource is attached.
2. Press DE-ASIGN.
If the selected destination does not include a resource, one of two things will occur:
• If the panel is in MC mode, park the current destination (switch same source number to destination).
• If the panel is not in MC mode, it displays the MC MODE? message.

The ability of a panel to de-assign a resource using the de-assign button will depend on the priority assigned to
the panel and the resource in the NK-VRC virtual routing core.
RCP-QE User Guide (v02) Operating the RCP-QE • 5–7
