To set up a menu:
1. Open the RCP-QE Panel Configuration editor (see "Opening the RCP-QE Panel Configuration Editor" on
page 4–4).
2. Select the Menu Details tab.
3. In the Number of menus box, enter or select the number of menus to match the requirements of your routing
switcher system.
4. Click Update.
5. In the Menu Number 1 row:
a. Click inside the Menu Name column and enter a name for the menu. The name can be up to 8 characters.
This menu (Menu 0) is by default the first menu.
b. Press Enter.
c. Click the Fallback Mode column and use the list to select a fallback mode. Use the information in
Table 4.2 as a guide.
Option
Fallback Off
First Menu
Previous Menu
Specified Menu
6. If you have selected Specified Menu as the fallback mode, enter the specific menu number in the Fallback
Menu column.
7. Define the next menu in the Menu Name column below the menus that you have defined previously. Repeat
steps 5 to 6 until you have defined all of the menus that you want to use.
8. Send the current configuration file to the device (see "Sending a Configuration File to a Device" on
page 4–33).

Setting Up Button Display Options on the RCP-QE

You can set up the display options for each type of button on the RCP-QE so that you can distinguish between what
types of functions have been assigned and whether or not the button is active. When a button is active, it shows the
color and inverse settings for the selected state. When a button is not active, it shows the color and inverse settings
for the default state.
4–14 • Setting Up the RCP-QE
Table 4.2 Fallback Mode Options
After a button in the menu is pressed, the RCP-QE remains on the
menu.
If you select Fallback Off, the corresponding value in the Fallback
Menu column is ignored. You must provide extra menu navigation
buttons within the menu so that you can exit from the menu.
After a button in the menu is pressed, the RCP-QE returns to the first
menu (Menu 0 in the Menu Name column).
If the button that is pressed is assigned as a menu link or a menu
navigation button, then the RCP-QE goes to that menu.
After a button in the menu is pressed, the RCP-QE returns to the menu
that it was on prior to the current menu.
If the button that is pressed is assigned as a menu link or a menu
navigation button, then the RCP-QE goes to that menu.
After a button in the menu is pressed, the RCP-QE returns to the menu
specified in the Fallback Menu column.
If the button that is pressed is assigned as a menu link or a menu
navigation button, then the RCP-QE goes to that menu.
Function
RCP-QE User Guide (v02)
