Loading Factory Defaults Using DashBoard

If you need to return the RCP-QE to a known configuration, you can use DashBoard to load the factory defaults.
To load the factory defaults:
1. Open the RCP-QE Panel Configuration editor for the RCP-QE (see "Opening the RCP-QE Panel
Configuration Editor" on page 4–4).
2. Select the Configuration tab.
3. In the Configuration section, select the Load Factory Defaults check box.
4. Send the current configuration file to the device (see "Sending a Configuration File to a Device" on
page 4–33). Ensure that only the Home page is selected in the Send Config to NK Device dialog box.
De-select all other pages or they will be sent to the device as well, thus changing the factory defaults.
The factory defaults are loaded.

This defaults the RCP-QE panel configuration (Panel Configuration editor) only, and not the connection
configuration (Connection Editor).

Saving the Current Configuration for the RCP-QE

The parameters that you have set up on the Panel Configuration editor tab for an RCP-QE are stored in a
configuration file. When you have finished making changes to the configuration of the RCP-QE, you should save
the configuration file and then add the location of this file to the File Navigator pane so that you can open it later.
Saving a New Configuration File
To save a new configuration file:
1. Select the Panel Configuration editor tab containing the configuration that you want to save.
2. Click Save As (
The default location is Desktop\Documents.
3. Navigate to the folder in which you want to save the configuration file.
4. Click Save.
Adding a Directory to File Navigator
To add the configuration file location to the File Navigator pane:
1. In the File Navigator pane, click Add a directory (
The Browse For Folder window opens.
2. Navigate to the folder where you saved the configuration file.
3. Select the folder.
4. Click OK.
The folder and any saved configuration files can now be accessed via the File Navigator pane.
Saving an Existing Configuration
To save an existing configuration:
1. Select the Panel Configuration editor tab containing the configuration that you want to save.
2. In the File Navigator pane, select the configuration file to which you want to save the current configuration.
3. Click to save the current configuration.
4–32 • Setting Up the RCP-QE
) to save the current configuration.
).
