CHAPTER 29 • CLICK 421
250
SmartSensor Driver
When you open the SmartSensor driver, you will see three tabs: Setup, About and Diag-
nostics.
Under the Setup tab, you can change the settings affecting the setup of the Click device (see
Figure 28.4 and Table 28.2).
Setting
Description
Location
Device ID
Baud Rate
Table 28.2 – SmartSensor Driver Setup Tab
Under the About tab, you can view information about your Click 421 (see Figure 28.5 and
Table 28.3).
Figure 28.4 – SmartSensor Driver Setup Tab
Description
Shows a description of the device being configured. This is only for
your information and does not affect the operation of the device.
Displays the location of the device being configured. This is only for
your information and does not affect the operation of the device.
Gives the ID number of the device being configured, which is used
to identify the device when you are connecting to it. By default, this
number is the last five digits of the serial number, which can be found
under the About tab or on the barcode sticker on the bottom of the
device. It is recommended that you do not change this number unless
another device on the network has the same ID number.
Allows you to change the baud rate at which the device connects to
the sensor.
