Click 200 —
Lightning Surge Protector
In this chapter
13
The Click 200 module is designed to protect SmartSensors from surges on all power and
communication connections, suppressing power surges for DC power, half-duplex RS-485
communication and full-duplex RS-232 communication with CTS and RTS.
The Click 200 can also be used to protect any device from surges from the SmartSensor or
any other device with 9–28 VDC power or RS-485 or RS-232 communication.
˽ Physical Features
˽ Installation
Figure 13.1 – The Click 200
