24.8 and Table 24.5).
Setting
Baud Rate
Flow Control
Parity
Stop Bits
Data Bits
Active Port
Latency
Table 24.5 – Expert Driver Comm Tab
The Autobaud subtab allows you to configure how the device autobauds (see Figure 24.9
and Table 24.6).
Figure 24.8 – Expert Driver Comm Tab
Description
Allows you to change the baud rate at which the device connects to
the sensor.
Is used for configuring hardware handshaking. This option is currently
not available.
Allows you to set parity error checking.
Allows you to set the number of stop bits.
Shows you the number of data bits being sent. This option currently
cannot be changed.
Indicates on which port you are communicating with the sensor. This
option cannot be changed.
Indicates the latency between the sensor and the Click device. This
option cannot be changed.
CHAPTER 24 • CLICK 304
215
