CHAPTER 9 • CLICK 110
102
Note
Some of the parameters mentioned below can only be configured in Click Supervi-
sor. Others can be configured by the front panel menu and/or the DIP switches. In
the case of the DIP switches, if that parameter is set to Hardware mode, it will be
grayed out in Click Supervisor, meaning you can view but not change the setting. If
you would like to set it using Click Supervisor, you will have to flip those switches on
the device.
The Click 110 can be configured using the Expert driver (see Figure 9.9).
After you have made configuration changes on the driver and saved it to the Click device,
the word "current" will appear after it to indicate the driver is currently loaded onto the
device.
The Backups option can be used to read configurations that have previously been saved to
file. See Chapter 5 for more information.
Expert Driver
The Expert driver contains two tabs, System and Diagnostics; the System tab is then sub-
divided further.
The System > General tab lets you change general information about your device. The tab
has the following parameters (see Figure 9.10 and Table 9.15):
Figure 9.9 – Selecting a Driver
