The Power Plant
In this chapter
1
Power and surge protection are provided to your devices via the Click modules that make
up what is known as the power plant (see Figure 1.1). Assembling the power plant is the first
step in installing your Click devices.
˽ Connecting to a Circuit Breaker
˽ Connecting AC Surge Protection
˽ Connecting Power
Figure 1.1 – The Click Power Plant
