1 Introduction

1.1 Purpose of this Operating Guide

This Operating Guide provides information for safe installation and setup of a VLT® Extended Relay Card MCB 113 option used in the
®
VLT FC drive series.
The Operating Guide is intended for use by qualified personnel only. Personnel must be familiar with the VLT
Read and follow the instructions before installation and setup, and ensure that instructions for safe installation and setup are observed.
Always keep these instructions available with the drive.

1.2 Trademarks

®
VLT is a registered trademark for Danfoss A/S.

1.3 Document Version

This operating guide is regularly reviewed and updated. All suggestions for improvement are welcome. See document version and
changes applied in table 1.
The original language of this manual is English.
Table 1: Version and Changes Applied
Document version
AQ322553864968, version 0101 Option now also applicable for VLT® HVAC Drive FC 102, VLT® Refrigeration Drive FC 103, and VLT®

1.4 Additional Resources

More information resources are available to understand advanced drive functions and programming.
• The VLT® FC Series Operating Guides provide information required to install and commission the drive for given applications.
• The VLT® FC Series Programming Guides provide greater detail on working with parameters.
• VLT® FC Series Design Guides provide detailed capabilities and functionality to design motor control systems for various
applications.
Technical documentation for other product options is available at www.danfoss.com.

1.5 Product Overview

1.5.1 Intended Use

The VLT® Extended Relay Card MCB 113 is exclusively intended for use in option slot C1. The option is constructed as a standard C1
option compatible with the following VLT® FC Series:
