Operating Guide | VLT® Extended Relay Card MCB 113
Voltage [V] Minimum waiting time (minutes)
525–690 –
Table 5: Discharge Time, VLT® AQUA Drive FC 202
Voltage [V] Minimum waiting time (minutes)
4
200–240 0.25–3.7 kW (0.34–5 hp)
380–480 0.37–7.5 kW (0.5–10 hp)
525–600 0.75–7.5 kW (1.0–10 hp)
525–690 –
Table 6: Discharge Time, VLT® AutomationDrive FC 301/FC 302
Voltage [V] Minimum waiting time (minutes)
4
200–240 0.25–3.7 kW (0.34–5 hp)
380–500 0.25–7.5 kW (0.34–10 hp)
525–600 0.75–7.5 kW (1–10 hp)
525–690 –
LEAKAGE CURRENT HAZARD
Leakage currents exceed 3.5 mA. Failure to ground the drive properly can result in death or serious injury.
Ensure the correct grounding of the equipment by a certified electrical installer.
-
ROTATING SHAFTS
Contact with rotating shafts and electrical equipment can result in death or serious injury.
Ensure that only trained and qualified personnel perform installation, start-up, and maintenance.
-
Ensure that electrical work conforms to national and local electrical codes.
-
Follow the procedures in this guide.
-
