Controls

Symptom
The system does not
respond to the remote
control.
The system does not
respond to the touch-panel
control.
12 - 4
Problem
No, low, or dead batteries
in the remote control.
The batteries are installed
incorrectly in the remote
control.
The room lights operate in
the 38 Khz range and
interfere with the remote
control signals.
The infrared sensor is not
receiving signals from the
remote control.
The external infrared
sensor is not operating
properly.
The remote control is set to
the wrong channel ID.
The RS-232 serial port is
not configured as a
touch-panel input.
Corrective action
Install four AAA batteries in the remote control.
Insert the batteries in the correct +/- position.
Turn off the lights in the room and try the remote
control again.
To check the remote control: Point the remote control
directly at the system or camera and press a button.
If the light on the system flashes, the remote control
works properly.
Make sure you are pointing the remote control at the
infrared sensor on the front of the system or the
camera.
Check the connections between the rear panel, cable
adapter, and infrared sensor cable.
Follow steps 3 - 7 in Configuring the Remote Control
Channel ID on page 10-2
channel ID to 3. Then follow the entire procedure to
configure the system and remote control channel ID
settings.
Go to Admin Settings > General Settings > Serial
Port and verify the following:
• Baud Rate is set to the same value on the
system as on the touch-panel.
• RS-232 Mode is set to Control.
• The touch-panel is connected to the port that is
configured as a touch-panel port.
to set the remote control
