- Page 1 TELE RADIO TIGER G2 Installation instructions D8-2, D8-4 Language: English (original language) IM-TG2-XX002-A01-ALL...
-
Page 2: Table Of Contents
Chapter 4: INSTALLERS GUIDE Functionality Connect MODBUS Configuration settings for Tiger receiver and transmitter Configuration settings for the MODBUS communication between D8-2/D8-4 and Tiger receiver Chapter 4: RoHS and WEEE Chapter 5: Guarantee, service, repairs and maintenance - 2 -... -
Page 3: Chapter 1: Customer Information
During the guarantee/ warranty period, Tele Radio AB may replace the product or faulty parts with new. Work under guarantee/ warranty must be carried out by Tele Radio AB or by an authorized service center specified by Tele Radio AB. Contact your Tele Radio AB representative if you need support or service. - Page 4 WARNINGS & RESTRICTIONS IMPORTANT! Tele Radio remote controls are often built into wider applications. We recommend that the system is provided with a wired emergency stop where necessary. NOTE! We recommend that the functionality of the STOP button is being tested at a regular basis: At a minimum, when used for 200 hours.
-
Page 5: Chapter 2: System Information
CHAPTER 2: SYSTEM INFORMATION APPLICATION AREA FOR D8-2/D8-4 ANALOGUE OUTPUT MODULE The Tele Radio analogue output module D8-2/D8-4 is aimed to be used in applications with analogue functions. All MN, MD and MX Tiger receivers support D8-2/D8-4. - 5 -... -
Page 6: Chapter 3: Product Pages
Chapter 3: PRODUCT PAGES CHAPTER 3: PRODUCT PAGES D8-2/D8-4 CIRCUIT BOARD DESCRIPTION 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1-16 1. AOUT1 8. GND 15. RS485A 2. AOUT2 9. -
Page 7: Mount D8-4 Inside The Receiver
Chapter 3: PRODUCT PAGES MOUNT D8-4 INSIDE THE RECEIVER WARNING! The receiver must NOT be opened by any other than a qualified installer. Make sure to turn the electricity off before opening the receiver. WARNING! Do not touch the area marked with danger when the receiver has been powered by electricity. -
Page 8: Chapter 4: Installers Guide
The analogue output modules are connected to the receiver with the RS485/MODBUS. IMPORTANT! The Tiger system supports a maximum of four D8-2/D8-4 units. If all four modules are connected to the receiver, unit one and two will have full functionality while units three and four will only have limited functionality. -
Page 9: Connect Modbus
COMMUNICATION BETWEEN D8-2/D8-4 AND TIGER RECEIVER Configure D8-2/D8-4 Analogue input module: 1. Connect D8-2/D8-4 unit to the PC program Settings Manager. 2. Go to MODBUS_ID and set slave address for the D8-2/D8-4 unit, (e.g. 1). 3. Save the settings. - 9 -... - Page 10 1. Connect Tiger receiver to the PC program Settings Manager. 2. Go to MODBUSTDEVICES and set DEVICETYPE connected to Tiger receiver. 3. Under section MODBUSDEVICES, go to DEVICEID and set slave address for the D8-2/D8-4 unit, (e.g. 1). 4. Under section COMMONRADIO, go to FLAGS and diable cable control for RS485.
-
Page 11: Chapter 4: Rohs And Weee
(WEEE), Tele Radio AB strives to minimize the use of hazardous materials, promotes reuse and recycling, and reduces emissions to air, soil and water. When a commercially viable alternative is available, Tele Radio AB strives to restrict or eliminate substances and materials that pose an environmental, health or safety risk. -
Page 12: Chapter 5: Guarantee, Service, Repairs And Maintenance
The Tele Radio AB products are covered by a guarantee/warranty against material, construction and manufacturing faults. During the guarantee/warranty period, Tele Radio AB may replace the product or faulty parts. Work under guarantee/warranty must be carried out by Tele Radio AB or by an authorized service centre specified by Tele Radio AB. - Page 13 ...
