Introduction; Specifications; Local Operation - LMI Excel XR Series Manual

Flow Display
The accuracy of the flow value as shown on the pump display is highly dependent on the
specific application. Calibration is necessary in order to display an accurate measure of the flow.
Spills
CAUTION: Spills of Dangerous chemicals should be cleaned up immediately.

2.0 Introduction

LMI's metering pumps deliver the highest level of repetitive accuracy and reliability
with the capability to pump a wide range of chemicals. Our comprehensive selection
of pumps means you get the right pump for the right application. Every one of our
pumps is engineered to exceed expectations and is backed by a global network of
highly trained field engineers and aftersales support.
This manual assumes the reader is familiar with commissioning and programming
Modbus RTU devices.

2.1 Specifications

Table 1: Modbus RTU Specifications
Modbus RTU Connector
Maximum Cable Length
Slave Address Range
Line Termination
Supported transmission speeds
Stop Bits
Parity

3.0 Local Operation

This manual covers basic features supported in the Excel
descriptions of Modbus features.
5 Pin Reverse Key Female M12 (B-Code)
1200 meters at 9.6 Kbits/s
1000 meters at 115.2 Kbits/s
1-125
On/Off (Software Configurable)
9600, 19200, 38400, 115200 (selectable or
automatically detected)
1 or 2 (Software Configurable)
Even, Odd, or None (Software Configurable)
®
INTRODUCTION
XR Series pumps and complete
