SECTION 1 - INTRODUCTION

LMI is the world's most versatile manufacturer
®
of economical and efficient metering pumps.
This manual addresses the installation, maintenance
and troubleshooting procedures for manually and
externally controlled pumps. LMI
network of stocking representatives and authorized
repair centers to give you prompt and efficient
service.
Note:
P l e a s e r e v i e w t h i s m a n u a l c a r e f u l l y.
Pay particular attention to warnings and
precautions. Always follow good safety
procedures, including the use of proper clothing,
eye and face protection.

1.1 SPECIFICATIONS

(where X is any number;
Operating
Temperature
Voltage
Frequency
Max. Current
Wattage
Battery
Fuse
Time-lag, 5mm x 20mm
Note:
The battery and fuse are internal, factory
serviceable parts, and must be replaced by the
factory or a qualified distributor with parts of the
same type and rating.
1
has a worldwide
®
AD2XY
where Y is 1, or 8)
14 to 113°F
–10 to 45°C
110 to 120 V
50 to 60 Hz
2.0 A
25 W
AD2
N/A
Bel Fuse 5HT1.25-R
Instruction Manual
AD2XY
(where X is any number;
where Y is 2,3,4,5,6,7, or 9)
14 to 113°F
–10 to 45°C
220 to 240 V
50 to 60 Hz
1.0 A
22 W
Table 1
AD8
N/A
Bel Fuse 5HT 2-R
Time-lag, 5mm x 20mm
Table 2
AD8XY, or AD9XY
(where X is any number;
where Y is any number)
14 to 113°F
–10 to 45°C
95 to 240 V
50 to 60 Hz
1.4 A
20 W
AD9
Panasonic BR1225 or
Renata CR1225 or
Energizer/Eveready
CR1220
Bel Fuse 5H 2-R
Time-lag, 5mm x 20mm
