LMI Excel XR Series Manual page 14

63 0x003F Digital Input 4 Config
64 0x0040 Digital Input 4 State
65 0x0041 Analog Input 1 Config
66 0x0042 Analog Input 2 Config
67 0x0043 Digital Output 1 Config
68 0x0044 Digital Output 1 State
69 0x0045 Digital Output 2 Config
70 0x0046 Digital Output 2 State
71 0x0047 Analog Output Config
MODBUS SOFTWARE DEFINITION
Read/write the configuration for Digital Input 4 an
enumeration with a range 0-5:
0: Digital Input = Disabled
1: Digital Input = RemoteOnOff
2: Digital Input = FloatSwitch_Empty
3: Digital Input = FloatSwitch_Low
4: Digital Input = RemoteIntExtMode
5: Digital Input = PacingPulse
Read/write the Contact State for Digital Input 4 as an
integer representing an enumeration (0=NO - Normally
Open, 1=NC - Normally Closed).
Read/write the configuration for Analog Input 1 as an
enumeration:
0: Analog Input = Disabled
1: Analog Input = Pacing
2: Analog Input = Level
Read/write the configuration for Analog Input 2 as an
enumeration:
0: Analog Input = Disabled
1: Analog Input = Pacing
2: Analog Input = Level
Read/write the configuration for Digital Output 1 as an
enumeration:
0: Digital Output = Disabled
1: Digital Output = StrokePulse
2: Digital Output = PumpRunning
3: Digital Output = PumpStandby
4: Digital Output = AlarmOut
5: Digital Output = INTEXTMode
6: Digital Output = UserAlarmOut
7: Digital Output = PumpStopped
8: Digital Output = TimedEvent
Read/write the Contact State for Digital Output 1 as an
enumeration:
0=NO - Normally Open
1=NC - Normally Closed
Read/write the configuration for Digital Output 2 as an
enumeration:
0: Digital Output = Disabled
1: Digital Output = StrokePulse
2: Digital Output = PumpRunning
3: Digital Output = PumpStandby
4: Digital Output = AlarmOut
5: Digital Output = INTEXTMode
6: Digital Output = UserAlarmOut
7: Digital Output = PumpStopped
8: Digital Output = TimedEvent
Read/write the Contact State for Digital Output 2 as an
enumeration:
0=NO - Normally Open
1=NC - Normally Closed
Read/write the configuration for the Analog Output as
an enumeration:
