LMI Excel XR Series Manual page 12

33 0x0021 Timed Event1 Start Time
Hour
34 0x0022 Timed Event1 Start Time
Minute
35 0x0023 Timed Event1 Start Time
AM/PM
36 0x0024 Timed Event1 Duration
37 0x0025 Timed Event1 Flow
38 0x0026 Timed Event1 Enabled
39 0x0027 Timed Event2 Start Time
Hour
40 0x0028 Timed Event2 Start Time
Minute
41 0x0029 Timed Event2 Start Time
AM/PM
42 0x002A Timed Event2 Duration
43 0x002B Timed Event2 Flow
44 0x002C Timed Event2 Enabled
45 0x002D Timed Event3 Start Time
Hour
46 0x002E Timed Event3 Start Time
Minute
47 0x002F Timed Event3 Start Time
AM/PM
48 0x0030 Timed Event3 Duration
49 0x0031 Timed Event3 Flow
MODBUS SOFTWARE DEFINITION
This must be set prior to configuring event parameters.
The other timed events will be based on the set day.
Read/write the Hour for Timed Event 1 on the currently
set day for Timed Event Mode as an integer (1-12).
Read/write the Minutes for Timed Event 1 on the
currently set day for Timed Event Mode as an integer
(0-60).
Read/write AM/PM for Timed Event 1 on the currently
set day for Timed Event Mode as an enumeration (0 =
AM, 1 = PM).
Read/write the duration for Timed Event 1 on the
currently set day for Timed Event Mode an integer
representing minutes with a valid range of 1-1439.
Read/write the flowrate for Timed Event 1 on the
currently set day for Timed Event Mode as an integer
representing XX.XX GPH/LPH format. The range is
0000-9999.
Read/write the status of Timed Event 1 on the
currently set day for Timed Event Mode as an
enumeration (0 = OFF, 1 = ON).
Read/write the Hour for Timed Event 2 on the currently
set day for Timed Event Mode as an integer (1-12).
Read/write the Minutes for Timed Event 2 on the
currently set day for Timed Event Mode as an integer
(0-60).
Read/write AM/PM for Timed Event 2 on the currently
set day for Timed Event Mode as an enumeration (0 =
AM, 1 = PM).
Read/write the duration for Timed Event 2 on the
currently set day for Timed Event Mode as an integer
representing minutes with a valid range of 1-1439.
Read/write the flowrate for Timed Event 2 on the
currently set day for Timed Event Mode as an integer
representing XX.XX GPH/LPH format. The range is
0000-9999.
Read/write the status of Timed Event 2 on the
currently set day for Timed Event Mode as an
enumeration (0 = OFF, 1 = ON).
Read/write the Hour for Timed Event 3 on the currently
set day for Timed Event Mode as an integer (1-12).
Read/write the Minutes for Timed Event 3 on the
currently set day for Timed Event Mode as an integer
(0-60).
Read/write AM/PM for Timed Event 3 on the currently
set day for Timed Event Mode as an enumeration (0 =
AM, 1 = PM).
Read/write the duration for Timed Event 3 on the
currently set day for Timed Event Mode as an integer
representing minutes with a valid range of 1-1439.
Read/write the flowrate for Timed Event 3 on the
currently set day for Timed Event Mode as an integer
representing XX.XX GPH/LPH format. The range is
0000-9999.
