Introduction; Specifications; Local Operation - LMI Excel XR Series Manual

Flow Display
The accuracy of the flow value as shown on the pump display is highly dependent on the
specific application. Calibration is necessary in order to display an accurate measure of the flow.
Spills
CAUTION: Spills of Dangerous chemicals should be cleaned up immediately.

2.0 Introduction

LMI's metering pumps deliver the highest level of repetitive accuracy and reliability
with the capability to pump a wide range of chemicals. Our comprehensive selection
of pumps means you get the right pump for the right application. Every one of our
pumps is engineered to exceed expectations and is backed by a global network of
highly trained field engineers and aftersales support.
The PROFIBUS DP interface conforms to the PROFIBUS DP-V0 standard for cyclic
data transmission. This manual assumes the reader is familiar with commissioning
and programming PROFIBUS devices.

2.1 Specifications

Table 1: PROFIBUS DP Specifications
PROFIBUS Implementation Class
PROFIBUS Connector
Maximum Cable Length
Slave Address Range
Line Termination
Supported transmission speeds

3.0 Local Operation

This manual covers basic features supported in the Excel
descriptions of PROFIBUS features.
DP-V0
5 Pin Reverse Key Female M12 (B-Code)
1200 meters at 9.6 Kbits/s
1000 meters at 115.2 Kbits/s
200 meters at 1.5 Mbits/s
100 meters at 12 Mbits/s
1-125
On/Off (Software Configurable)
9600 to 12 Mbit/s (auto detected)
®
INTRODUCTION
XR Series pumps and complete
