LMI Excel XR Series Manual page 18

2 0x0002 Int/Ext Operating Mode
3 0x0003 Tank Low
4 0x0004 Tank Empty
5 0x0005 Manual Mode
6 0x0006 Analog Mode
7 0x0007 Pulse Mode
8 0x0008 Batch Mode
9 0x0009 Cycle Timer Mode
10 0x000A Timed Event Mode
11 0x000B 100% Mode
12 0x000C Prime Mode
13 0x000D Slow Mode
14 0x000E Units
15 0x000F Pump Calibrated
16 0x0010 Keypad Locked
17 0x0011 Digital Output 1
18 0x0012 Digital Output 2
19 0x0013 Digital Input 1
20 0x0014 Digital Input 2
21 0x0015 Digital Input 3
22 0x0016 Digital Input 4
23 0x0017 Home Screen
24 0x0018 Batch Mode Dosing
25 0x0019 Cycle Timer Startup
Delay
26 0x001A Cycle Timer Pump Active
27 0x001B Weekly Timed Event
Active
MODBUS SOFTWARE DEFINITION
Read the Internal/External Operating Mode Discrete
Input: (0 = internal, 1 = external).
Read the Tank Low Discrete Input: (0 = Not low, 1 =
Tank Low).
Read the Tank Empty Discrete Input: (0 = Not empty, 1
= Empty).
Read the Manual Mode Discrete Input: (0 = Not in
manual mode, 1 = In manual mode).
Read the Analog Mode Discrete Input: (0 = Not in
analog mode, 1 = In analog mode).
Read the Pulse Mode Discrete Input: (0 = Not in pulse
mode, 1 = In pulse mode).
Read the Batch Mode Discrete Input: (0 = Not in batch
mode, 1 = In batch mode).
Read the Cycle Timer Mode Discrete Input: (0 = Not in
cycle timer mode, 1 = In cycle timer mode).
Read the Timed Event Mode Discrete Input: (0 = Not in
timed event mode, 1 = In timed event mode).
Read the 100% Mode Discrete Input: (0 = Not in 100%
mode, 1 = In 100% mode).
Read the Prime Mode Discrete Input: (0 = Not in prime
mode, 1 = In prime mode).
Read the Slow Mode Discrete Input: (0 = Not in slow
mode, 1 = In slow mode).
Read the Units Discrete Input: (0 = English, 1 = Metric).
Read the Pump Calibrated Discrete Input: (0 = Not
calibrated, 1 = Calibrated).
Read the Keypad Locked Discrete Input: (0 = unlocked,
1 = locked).
Read the Digital Output 1 Discrete Input: (0 =
Unswitched, 1 = Switched).
Read the Digital Output 2 Discrete Input: (0 =
Unswitched, 1 = Switched).
Read the Digital Input 1 Discrete Input: (0 = Unswitched,
1 = Switched).
Read the Digital Input 2 Discrete Input: (0 = Unswitched,
1 = Switched).
Read the Digital Input 3 Discrete Input: (0 = Unswitched,
1 = Switched).
Read the Digital Input 4 Discrete Input: (0 = Unswitched,
1 = Switched).
Read the Home Screen Discrete Input: (0=homescreen
not displayed, 1=homescreen displayed).
Read the Batch Mode Dosing Discrete Input: (0=No,
1=Yes).
Read the Cycle Timer Startup Delay Discrete Input:
(0=No, 1=Yes).
Read the Cycle Timer Pump Active Discrete Input:
(0=No, 1=Yes).
Read the Weekly Timed Event Active Discrete Input:
(0=No, 1=Yes).
