LMI Excel XR Series Manual page 11

13 0x000D Pulse Mode Volume
,
0x000E
15 0x000F Pulse Mode Units
16 0x0010 Pulse Mode Pulse Width
17 0x0011 Batch Mode Volume
19 0x0013 Batch Mode Time
21 0x0015 Batch Mode Units
22 0x0016 Batch Mode Pulse Width
23 0x0017 Batch Mode Accumulate
24 0x0018 Analog Mode P1 Volume
25 0x0019 Analog Mode P1 Current
26 0x001A Analog Mode P2 Volume
27 0x001B Analog Mode P2 Current
28 0x001C Cycle Mode Cycle Time
29 0x001D Cycle Mode Duration
30 0x001E Cycle Mode Delay
31 0x001F Cycle Mode Flow
32 0x0020 Timed Event Day
MODBUS SOFTWARE DEFINITION
Read/write the volume to deliver in Pulse Mode as an
integer with a valid range is 0.0 to 10000.00. This
value spans two registers.
Read/write the units setting for Pulse Mode
enumeration (0=Small, 1=Large). Large will use
Gallons or Liters based on global units setting. Small
will use fl oz. or mL based on global units setting.
Read/write the pulse width for Pulse Mode as an
integer representing msec. The valid range is 4 - 60 in
increments of 4.
Read/write the volume to deliver in Batch Mode with a
valid range of 0.0 to 10000.00. This value spans two
registers.
Read/write the dosing time for Batch Mode with a valid
range of 1-86400 Seconds. This value spans two
registers.
Read/write the units setting for Batch Mode as an
enumeration (0=Small, 1=Large). Large will use
Gallons or Liters based on global units setting. Small
will use fl oz. or mL based on global units setting.
Read/write the pulse width for Batch Mode as an
integer representing msec. The valid range is 4 - 60 in
increments of 4.
Read/write the Pulse Accumulator for Batch Mode as
an enumeration (0 = Off, 1 = On).
Read/write the flowrate for P1 in Analog Mode as an
integer representing XX.XX GPH/LPH format. The
range is 0000-9999.
Read/write the Current for P1 in Analog Mode as an
integer representing XX.X mA. The valid range is 0.0-
20.0.
Read/write the flowrate for P2 in Analog Mode as an
integer representing XX.XX GPH/LPH format. The
range is 0000-9999.
Read/write the Current for P2 in Analog Mode as an
integer representing XX.X mA. The valid range is 0.0-
20.0.
Read/write the Cycle Time for Cycle Timer Mode as an
integer representing minutes with a valid range of 1-
1439.
Read/write the Duration for Cycle Timer Mode as an
integer representing minutes with a valid range of 1-
1439 The Duration is the inactive period in Cycle
Mode.
Read/write the Delay Time for Cycle Timer Mode as
an integer representing minutes with a valid range of
0-1439. The Delay Timer is the first inactive period
prior to starting the cycle.
Read/write the flowrate for Cycle Timer Mode as an
integer representing XX.XX GPH/LPH format. The
range is 0000-9999.
Read/write the Day of the Week for Timed Event Mode
as an integer (1-7) that represents a day of the week.
