3.1 Display Navigation

Navigation through display screens is done using the Up, Down, and Multi-Function
buttons. The settings screen is shown in the example below (
Figure 1). The scroll bar on the side of the display screen indicates there are more settings
available on another page.

Figure 1: Display Navigation

3.2 Settings

To access the settings screen (Figure 2) press Settings
to the function desired and press Enter
settings will need to be saved by pressing Save
previous screen without saving.

Figure 2: Settings

LOCAL OPERATION
in the home screen. Navigate
. Follow the prompts to enter new settings. New
. Press Exit
Scroll Bar
Multi-Function Icons
to return to the
