LMI Excel XR Series Manual page 13

50 0x0032 Timed Event3 Enabled
51 0x0033 Timed Event4 Start Time
Hour
52 0x0034 Timed Event4 Start Time
Minute
53 0x0035 Timed Event4 Start Time
AM/PM
54 0x0036 Timed Event4 Duration
55 0x0037 Timed Event4 Flow
56 0x0038 Timed Event4 Enabled
57 0x0039 Digital Input 1 Config
58 0x003A Digital Input 1 State
59 0x003B Digital Input 2 Config
60 0x003C Digital Input 2 State
61 0x003D Digital Input 3 Config
62 0x003E Digital Input 3 State
MODBUS SOFTWARE DEFINITION
Read/write the status of Timed Event 3 on the
currently set day for Timed Event Mode as an
enumeration (0 = OFF, 1 = ON).
Read/write the Hour for Timed Event 4 on the currently
set day for Timed Event Mode as an integer (1-12).
Read/write the Minutes for Timed Event 4 on the
currently set day for Timed Event Mode as an integer
(0-60).
Read/write AM/PM for Timed Event 4 on the currently
set day for Timed Event Mode as an enumeration (0 =
AM, 1 = PM).
Read/write the duration for Timed Event 4 on the
currently set day for Timed Event Mode as an integer
representing minutes with a valid range of 1-1439.
Read/write the flowrate for Timed Event 4 on the
currently set day for Timed Event Mode as an integer
representing XX.XX GPH/LPH format. The range is
0000-9999.
Read/write the status of Timed Event 4 on the
currently set day for Timed Event Mode as an
enumeration (0 = OFF, 1 = ON).
Read/write the configuration for Digital Input 1 an
enumeration with a range 0-5:
0: Digital Input = Disabled
1: Digital Input = RemoteOnOff
2: Digital Input = FloatSwitch_Empty
3: Digital Input = FloatSwitch_Low
4: Digital Input = RemoteIntExtMode
5: Digital Input = PacingPulse
Read/write the Contact State for Digital Input 1 as an
integer representing an enumeration (0=NO - Normally
Open, 1=NC - Normally Closed).
Read/write the configuration for Digital Input 2 an
enumeration with a range 0-5:
0: Digital Input = Disabled
1: Digital Input = RemoteOnOff
2: Digital Input = FloatSwitch_Empty
3: Digital Input = FloatSwitch_Low
4: Digital Input = RemoteIntExtMode
5: Digital Input = PacingPulse
Read/write the Contact State for Digital Input 2 as an
integer representing an enumeration (0=NO - Normally
Open, 1=NC - Normally Closed).
Read/write the configuration for Digital Input 3 an
enumeration with a range 0-5:
0: Digital Input = Disabled
1: Digital Input = RemoteOnOff
2: Digital Input = FloatSwitch_Empty
3: Digital Input = FloatSwitch_Low
4: Digital Input = RemoteIntExtMode
5: Digital Input = PacingPulse
Read/write the Contact State for Digital Input 3 as an
integer representing an enumeration (0=NO - Normally
Open, 1=NC - Normally Closed).
