Panel View - SC&T VHE02EIP Manual

Panel View:

VHE02EIPT Front View
VHE02EIPR Front View
LED Instruction:
Status Color
POWER GREEN
LINK BLUE
HDMI BLUE
VGA BLUE
IR RED
Side View Dip Switch
Rear View Dip Switch
VHE02EIPT
ON：Power on
ON：HDBaseT Linking
Flash: Power saving mode
ON：Select HDMI Input
ON：Select VGA Input
Flash：IR Receiving or Sending
VHE02EIPR
ON：Power on
ON：HDBaseT Linking
Flash: Power saving mode
Flash：IR Receiving or Sending
