2 Controls

BNCLKO06 / 2020115
2.1

Physical Controls

On side-loaded, barrier washer-extractors, the virtual controls on the MilTouch™ touchscreen
control all machine functions needed on the soil side of the machine (see
MilTouch™ Controller Virtual Controls, page 7
ure 1 control all machine functions needed on the clean side of the machine.
Figure 1. Clean-Side Control Panel
4
BNCLKO06 0000254486
BNCLKO05.R01 0000254487 B.2 C.2 3/11/20 4:35 PM Released
). The buttons on the control panel shown in
A...
Emergency stop switch
B...
Clean-side buzzer (H2)
C...
Clean-side light (H3)
D...
Reposition button (S4)
E... Control on clean side button (S5)
3/12/20 1:16 PM Released
Section 2.3 : About the
Legend
Pellerin Milnor Corporation
Fig-
