Clean-Side Controls; Emergency Stop Switch (Locking Push Button); Figure 4 Emergency Stop Switch - Milnor MilTouch Operator's Manual

Controls

Clean-Side Controls

Clean-side buzzer (H2) — This buzzer (item B in
while the cylinder turns to the clean-side position (the discharge position).
Clean-side light
side door is unlocked and the machine is ready to be unloaded.
Reposition button
to the clean-side position, or rotates the drum to the next compartment on the clean side if the
drum is already on the clean side. This button can be used to align the inner and outer doors if
they are misaligned.
Control on soil side button
(cylinder) to the soil-side position.
BNVLUO01 / 2018513
2.2

Emergency Stop Switch (locking push button)

One or more emergency stop switches (pictured below) may be provided on the device. When
pressed, any emergency stop switch removes power from the machine controls, stops the ma-
chine, and locks in the depressed (switch actuated, machine stopped) position. When safe to do
so, turn the button clockwise to unlock the switch. To resume operation, perform the device's nor-
mal startup procedure.
Figure 4. Emergency Stop Switch
Stopped Position
NOTICE: Press the emergency stop switch immediately in an emergency situation.
Display or Action
6
(H3) — This light (item C in
(S4) — This button (item D in
(S5) — This button (item E in
Explanation
This symbol represents the emergency stop switch in Milnor
documents other than electrical wiring diagrams.
Figure 1 ) sounds at the end of a formula
Figure 1 ) illuminates to indicate the clean-
Figure 1 ) rotates the drum (cylinder)
Figure 1
