Close the window.

Modify Steam and Cooldown

Figure 21. Pop-up Controls for Steam and Cooldown Valves
Inject steam to raise or maintain the bath temperature. If the steam inlet valve is open,
touch to close it.
Inject cool water to gradually lower the bath temperature (perform a cooldown). If the
cooldown inlet valve is open, touch to close it.
Close the window.

Modify Cylinder Speed

Figure 22. Pop-up Controls for Cylinder Speed
Increase the rotation speed of the cylinder by 1 RPM.
Decrease the rotation speed of the cylinder by 1 RPM.
Close the window.

Modify Water Temperature

Figure 23. Pop-up Controls for Water Temperature
Increase the desired bath temperature by 1 degree (Celsius or Fahrenheit).
Decrease the desired bath water temperature by 1 degree (Celsius or Fahrenheit).
Pellerin Milnor Corporation
— Touch the box identified by item S on
— Touch the box identified by item C on
— Touch the box identified by item Tw on
Troubleshooting
Figure 17
.
Figure 17
.
Figure 17
.
29
