3.1.1.2

How to Lock the Outer (Shell) Door

If the outer doors are closed, the doors lock automatically when the following events occur.
The outer door on the soil side locks when:
• The operator powers-on the machine.
• The machine starts a formula.
• The operator touches
the clean side.
The outer door on the clean side locks when:
• The operator powers-on the machine.
• The machine starts a formula.
• The operator presses the Control on Soil Side button (
the soil-side position.
BNWVUO01 / 2020115
3.2

How to Open and Close the Inner Cylinder Doors

The inner and outer doors must be aligned before it is safe to open the inner door(s). If the inner
and outer doors are not aligned, close the outer door and use the AutoSpot™ feature to rotate the
cylinder until the doors are aligned.
3.2.1

How to Open the Inner (Cylinder) Door(s)

1. Hold the lever (item C in
thumb, as shown in the following figure.
Figure 5. Inner (Cylinder) Door Lock Mechanism
Pellerin Milnor Corporation
(on the Home display) from the soil side to position the basket on
Figure 5 ) and press the lock panel (item B in
BNWVUO02.T02 0000261893 B.2 A.5 1/2/20 2:19 PM Released
) to rotate the drum (cylinder) to
BNWVUO01 0000254603
BNWVUO01.C02 0000261953 B.2 A.3 1/2/20 2:19 PM Released
BNWVUO01.T01 0000254597 B.2 3/11/20 4:57 PM Released
Legend
A... Door handle
B...
Lock panel
C... Lever
D... Safety switch
Load and Unload
3/12/20 1:19 PM Released
Figure 5 ) with your
