Diagnostics
Symptom: Faulty output
Possible explanation
Incorrect OPTO
module used for the
output
Wiring fault
Blown fuse
96
Hydro-Control VI Installation Guide HD0455 Rev 1.9.0
Check
Required result
Voltage range for
OPTO module
the output module.
colour:
As a quick guide,
look at the colour of
the OPTO module
Red: DC module,
by looking though
typically up to 60v
the holes in the
DC
back of the
controller.
Black: AC module,
typically up to 110v
AC
When the OPTO
See User Guide for
switches on the
more details.
OPTO LED should
light up. Check
wiring whilst the
OPTO is on.
Remove rear cover
Continuity check
and check
ok, zero ohms.
continuity of the
fuse on the specific
OPTO module
using a meter.
Appendix B
Action required on failure
Contact Hydronix for correct
OPTO module rating.
Force relay to switch on and
check wiring. Go to Menu >
I/O Setup and Status. Select
output and switch on.
Contact Hydronix for
replacement fuse.
