Chapter 8
1 The System and Data Cards and USB memory stick
The Hydro-Control incorporates a System Card and a Data Card. These cards are accessed via
the top access plate. The identification, removal and replacement of these cards is described in
Chapter 2.
The System Card (Hydronix Replacement Part Number 0176)
1.1
The System Card holds the main operating files of the Hydro-Control. This is specific to the
type of unit and should not be changed between units. (Not applicable to HC06 v2)
The Data Card (Hydronix Replacement Part Number 0177)
1.2
The Data Card holds the mix log database and system settings. With the power supply off, this
can be removed and replaced if necessary. (Not applicable to HC06 v2)
USB Memory Stick
1.3
The USB ports
Figure 52: The Hydro-Control VI side view showing the USB ports
There are three USB ports sited on the left hand side when looking at the front of the unit. A
Memory Stick may be used for backing up and restoring recipes, system parameters and mix
log files.
If the Hydro-Control USB ports are difficult to access then a USB extension with a panel
mounted socket is available from Hydronix – Part Number 0175.
The Memory Stick may be inserted and removed with the power supply on. Do not remove the
Memory Stick when a backup or restore is in progress.
Backup, Restore and Upgrade
