Commissioning
5 System Parameters
To access the System Parameters page, press the Menu button
Parameters
The System Parameters – Page 1
5.1
Each of the items on the parameters page is described in the following pages. Greyed out
items are not required for the currently selected water mode.
Water Setup
Parameter
Water Mode
Pulses Per Litre
Water Meter Timeout
Fine Delivery
Fine Valve Inflight
Coarse Valve Inflight
36 Hydro-Control VI Installation Guide HD0455 Rev 1.9.0
.
Figure 23: The System Parameters screen
Units
None
Pulses Per
Litre/Gallon
Seconds
Litres/Gallons
Litres/Gallons
Litres/Gallons
Default Range
Metered Metered/Timed/Weighed
1 0.1 – 10,000 Pulses per Litre
0 – 2641.7 Pulses per Gallon
5 0 – 100 s
20 0 – 100 L
0 – 26.4 Gallons
0 0 – 100 L
0 – 26.4 Gallons
0 0 – 100 L
0 – 26.4 Gallons
Chapter 4
and then press System
