11. Alarm messages

Alarm message Description
The insulation resistance is lower than the
Alarm 1 (insulation fault)
response value R
The insulation resistance is lower than the
Alarm 2 (insulation fault)
response value R
Check L1-L2 for correct con-
Connection fault system
nection
Check E-KE connections for
Connection fault. E/KE not connected to PE
interruptions
Device error x.xx Internal device error
Overtemperature
Overtemperature coupling terminal L1/+ or L2/–
coupling
Overtemperature PGH
Overtemperature of the locating current injector • Wait for the end of the cool-down period
(isoxx1685DP)
Check date and time! Date and time have not been set yet
45
Action
• Determine cause of the insulation fault and eliminate it.
an1
• Determine cause of the insulation fault and eliminate it.
an2
• Check the wiring of terminals L1/+, and L2/- to the IT system
• Press the TEST button
• Check mains voltage
• Check fuses
• Check wiring of terminals E and KE to earth (PE)
• Press the TEST button
• Press the TEST button
• Switch the supply voltage on and off
• Contact Bender Service
• Check mains voltage level and eliminate any existing insulation
faults. After cooling down, the device switches on again automati-
cally at a temperature of 80 °C. This device behaviour is normal if a
high mains voltage and low insulation fault resistance have been
selected.
• Set local date and time
(in case of voltage failure buffer for three days)
Reference LED indicators
ALARM 1 lights up
ALARM 2 lights up
ALARM 1 + ALARM 2
See chapter "Connection"
flash in common
from page 16 .
mode
ALARM 1 + ALARM 2
See chapter "Connection"
flash in common
from page 16.
mode
SERVICE lights up
SERVICE lights up
SERVICE lights up
See chapter
"Clock" from page 38 .
