Settings
8.2 (2.6.2.4) Function 3
See chapter 8.2 (2.4.2.1.3) "Function 1".
8.2

(2.6.3) Digital output

In this menu, each digital output can be configured. See also
output".
8.2 (2.6.3.1) TEST
See chapter 8.2 (2.4.2.3.1) "TEST".
8.2 (2.6.3.2) Function 1
See chapter 8.2 (2.4.2.1.3) "Function 1".
8.2 (2.6.3.3) Function 2
See chapter 8.2 (2.4.2.1.3) "Function 1".
8.2 (2.6.3.4) Function 3
See chapter 8.2 (2.4.2.1.3) "Function 1".
8.2

(2.7) Inputs

In this menu, each digital input can be configured. For this purpose, select a digital input.
•Dig. input 1 (BS 2/1)
•Dig. input 2 (BS 2/2)
8.2

(2.7.1) Mode

See chapter 8.2 (2.4.3.1) "Mode".
8.2

(2.7.2) t(on)

Seechapter 8.2 (2.4.3.2) "t(on)".
8.2

(2.7.3) t(off)

See chapter 8.2 (2.4.3.3) "t(off)".
8.2

(2.7.4) Function

See chapter 8.2 (2.4.3.4) "Function".
8.2

(2.8) Device

8.2

(2.8.1) Name

8.2

(2.8.2) Trigger

See chapter 8.2 (2.4.4.3) "Trigger".
37
Settings
8.2
See
8.2
chapter 8.2 (2.4.2.3) "Digital
The service menu can only be accessed by Bender service staff.
8.2
The ISOMETER® stores certain measured values for a specific period of time. These data
can be viewed at the "Data meas. values" menu item. Navigate through the different
views using the
•Data - isoGraph
•Data - Insulation
•Data - Voltage
•Data - PGH
(isoxx1685DP only)
•Data - Temperature

(2.8.3) Fault memory

chapter 8.2 (2.4.4.4) "Fault memory".

(2.9) Service

(3.0) Data measured values

and buttons:
Displays the insulation resistance and chronological sequence.
Displays the current insulation resistance and the system leak-
age capacitance.
Displays the system voltages and the partial voltages to earth
Displays measuring current, locating current, performance and
insulation fault location mode.
Mains connection and locating current injector
