Command access MLRK1 Series Insert Instructions page 5

7
Reinstall the Head Assembly.
Head Assembly
8
Flip the Push Pad over and remove the Dogging Assembly underneath (four screws).
9
Install the Magnet Bracket by first hooking the bottom tab under the Front Activating Bracket.
Then press on the top plane to snap the Magnet Bracket in place.
10
Once snapped in place, tighten the Top Screw to secure the Bracket in position.
U S c u s t o m e r s u p p o r t 1 - 8 8 8 - 6 2 2 - 2 3 7 7 | w w w . c o m m a n d a c c e s s . c o m | C A c u s t o m e r s u p p o r t 1 - 8 5 5 - 8 2 3 - 3 0 0 2
installation instructions
Dogging Assembly
Press Here
Top Screw
5
# 2 0 3 7 9 _ L
