Specifications

7 Specifications

7.1 Power-dependent Specifications

Frequency converter
typical shaft output [kW]
Enclosure protection rating IP20
Output current
Shaft output [kW]
Continuous (3x380–440 V) [A]
Continuous (3x441–480 V) [A]
Intermittent (60 s overload) [A]
Continuous kVA (400 V AC) [kVA]
Continuous kVA (480 V AC) [kVA]
Maximum input current
Continuous (3x380–440 V) [A]
Continuous (3x441–480 V) [A]
Intermittent (60 s overload) [A]
More specifications
Maximum cable cross-section (mains, motor,
brake, and load sharing) [mm 2 (AWG)]
Estimated power loss at rated maximum load
1)
[W]
Weight, enclosure protection rating IP20 [kg
(lb)]
2)
Efficiency [%]
Table 7.1 Mains Supply 3x380–480 V AC
MG07B102
Design Guide
PK37 PK55 PK75
0.37 0.55 0.75
K1 K1 K1
0.37 0.55 0.75
1.2 1.7 2.2
1.1 1.6 2.1
1.9 2.7 3.5
0.9 1.2 1.5
0.9 1.3 1.7
1.2 1.6 2.1
1.0 1.2 1.8
1.9 2.6 3.4
20.9 25.2 30
2.3 (5.1) 2.3 (5.1) 2.3 (5.1)
96.2 97.0 97.2
