Product Overview

2 Product Overview

2.1 Enclosure Size Overview

Enclosure size depends on power range.
Enclosure K1
size
Enclosure
IP20
protection
Power
range
[kW (hp)] 0.37–2.2 (0.5–3.0)
3-phase
380–480 V
Power
range
[kW (hp)] 0.37–1.5 (0.5–2.0)
3-phase
200–240 V 1)
Power
range
[kW (hp)]
0.37–1.5 (0.5–2.0)
single-
phase
1)
200–240 V
Table 2.1 Enclosure Sizes
1) Single-phase and 3-phase 200–240 V products are launched on the market later.
MG07B102
Design Guide
K2 K3
IP20 IP20
3.0–5.5 (5.0–7.5) 7.5 (10)
2.2 (3.0) 3.7 (5.0)
2.2 (3.0) –
Danfoss A/S © 03/2016 All rights reserved.
K4 K5
IP20 IP20
11–15 (15–20) 18.5–22 (25–30)
– –
– –
