Hp Pod 20C Racks - HP Performance Optimized Datacenter 20c Maintenance And Service Manual

Item Component
Fire alarm and suppression
2
release control panel
ECS relays and ECS modules
3
EPO controller board and house
4
panel fuses
Dual power supplies with
5
battery backup

HP POD 20c racks

The standard HP installed rack is a 50U rack. The HP POD 20c contains a total of 10 IT racks.
During maintenance, if you remove filler panels for maintenance purposes, you must replace them. Cold-aisle
to hot-aisle separation must be maintained.
CAUTION:
the efficiency of the HP POD 20c thermal system. Filler panels are available from HP in 10-pack
quantities (part number AQ682A) and 100-pack quantities (part number AS993A).
For more information about racks and network cabling, see the HP Performance Optimized Datacenter
Networking Guide.
Description
•
Controls all fire systems within the HP POD 20c, including the
smoke detection system, fire suppression system, fire pulls, and
so on
•
Includes a battery backup system that provides backup power
to the fire system during a utility power loss
Relays for the ECS control, ECS communications, I/O connections,
and terminal block connections
Connections for the EPO system and fuses for other house panel
components
Provides 24 V DC power to the PLC, LED lighting, and ECS systems
If any racks contain empty RU space, use the HP POD 20c filler panels to maintain
Illustrated parts catalog 13
