End view shown
Item Component
Fire strobe light
1
Fire horn
2
EPO strobe
3
ECS power switch
4
Main light switch
5
Fire alarm manual button
6
Fire suppression abort button*
7
Fire alarm manual button
8
Fire suppression abort button*
9
*This is an optional component that might not be included.
Internal emergency status indicators
The HP POD 20c has one fire strobe light that indicates a fire alarm condition.
Description
Indicates a fire alarm condition within the HP POD 20c
Indicates a fire alarm condition within the HP POD 20c
Amber—An EPO event occurred and the HP POD 20c shut
down
Turns the main power to the 24V ECS system off and on
Turns power to the HP POD 20c lights off and on
Enables manual initiation of the fire system, which includes
activating the interior and exterior fire strobe lights and the
optional fire suppression system
Aborts the fire suppression system. A fire suppression abort
button is located next to each personnel door.
Enables manual initiation of the fire system, which includes
activating the interior and exterior fire strobe lights and the
optional fire suppression system
Aborts the fire suppression system. A fire suppression abort
button is located next to each personnel door.
