Sega Airline Pilots Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

1st PRINTING MAY 00
STD TYPE
OWNER'S MANUAL
SEGA ENTERPRISES, INC. USA
MANUAL NO. 4200-6479-01

Advertisement

Table of Contents
loading

Related Manuals for Sega Airline Pilots

Summary of Contents for Sega Airline Pilots

  • Page 1 1st PRINTING MAY 00 STD TYPE OWNER’S MANUAL SEGA ENTERPRISES, INC. USA MANUAL NO. 4200-6479-01...
  • Page 2 Warranty Your new Sega Product is covered for a period of 90 days from the date of shipment. This certifies that the Printed Circuit Boards, Power Supplies and Monitor are to be free of defects in workman- ship or materials under normal operating conditions. This also certifies that all Interactive Control Assemblies are to be free from defects in workmanship and materials under normal operating condi- tions.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION OF THE OWNERS MANUAL GENERAL PRECAUTIONS 1. PRECAUTIONS TO BE HEEDED FOR OPERATION 2. NAME OF PARTS 3. ACCESSORIES 4. ASSEMBLY AND INSTALLATION 9~16 5. PRECAUTIONS TO BE HEEDED WHEN MOVING MACHINE 6. CONTENTS OF GAME 18~20 7.

  • Page 4: Introduction Of The Owners Manual

    29” COLOR MONITOR INTRODUCTION OF THE OWNERS MANUAL SEGA ENTERPRISES, LTD., has for more than 30 years been supplying various innovative and popular amusement products to the world market. This Owners Manual is intended to provide detailed descriptions together with all the necessary installation, game settings and parts ordering information related to AIRLINE PILOTS STD TYPE, a new SEGA product.

  • Page 5: General Precautions 2~3

    General Precautions Follow Instructions: All operating and use instructions should be followed. Attachments: Do not use attachments not recommended by the product manufacturer as they may cause hazards. Accessories: Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product.
  • Page 6 Safety Check: Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition. Heat: The product should be situated away from heat sources such as radiators, heat registers, stoves, or other prod- ucts (including amplifiers) that produce heat.

  • Page 7: Precautions To Be Heeded For Operation 4~5

    1 . PRECAUTIONS TO BE HEEDED FOR OPERATION In order to prevent accidents, be sure to comply with the following points before and during operation. PRECAUTIONS TO BE HEEDED FOR OPERATION BEFORE STARTING THE OPERATION In order to avoid accidents, check the following before starting the operation: Check if all of the adjusters are in contact with the surface.
  • Page 8 PRECAUTIONS TO BE HEEDED DURING OPERATION To avoid injury and accidents, those who fall under the following catagories are not allowed to play the game: * Intoxicated persons * Those who have high blood pressure or heart problems. * Those who have experienced muscle convulsion or loss of consciousness when playing video games, etc.

  • Page 9: Name Of Parts

    2 . NAME OF PARTS WEIGHT lbs. WIDTH in. LENGTH in. HEIGHT in. GAME SPECIFICATIONS All measurements are and rounded UP 42” 60” 65” 669 LBS. DURING SHIPPING WHEN ASSEMBLED 37.25” 64” 73.75” 619 LBS.

  • Page 10: Accessories 7~8

    3 . ACCESSORIES...
  • Page 11 APPLIES TO ‘MODEL 3’ BOARDS CONTAINED IN THE FOLLOWING GAMES: LOST WORLD, VIRTUA FIGHTER 3, SUPER GT, SEGA BASS FISHING, STRIKER 2 HARLEY DAVIDSON, RALLY 2, DAYTONA 2, DIRT DEVILS, HOUSE OF THE DEAD 2, OCEAN HUNTER, STAR WARS TRILOGY, ZOMBIE REVENGE, CRAZY TAXI,...

  • Page 12: Assembly And Installation

    4 . ASSEMBLING AND INSTALLATION -Assembling should be performed as per this manual. Since this is a complex machine, erroneous assembling may cause damage to the machine, or malfunctioning to occur. -When assembling, be sure to perform work by plural persons. Depending on the assembly work, there are some cases in which performing the work by a single person can cause personal injury or parts damage.
  • Page 13 Take out the 2 screws, and remove the Plate Holder & Billboard Plate. From the rear of the Billboard, remove the 2 Bolt Lids and the Connector Lid by taking out 2 screws from each Loosen the 2 Bolts securing the Billboard Hook.
  • Page 14 Mount the Billboard by hanging on the Billboard Hook, secure the Billboard with 2 Bolts through the square holes of Bolt Lids previously removed, and connect the Connector. Install the 2 Bolt Lids and Connector Lid. Insert the Billboard Holder in place so as to fit the bolt positions, and fasten the bolts to secure the Billboard.
  • Page 15 SECURING IN PLACE (ADJUSTER ADJUSTMENT) Be sure to have all the Adjusters make contact with the floor surface. Unless the Adjusters come into contact with the floor surface, the Cabinet can move of itself, causing an accident. This machine has 4 each of casters and adjusters (shown below). When the installation position is determined, cause the adjusters to come into contact with the floor directly, make adjustments in a manner so that the casters will be raised approximately 5mm.
  • Page 16 POWER SUPPLY Ensure that the power cord is not exposed on the surface (passage, etc.). If exposed, they can be caught and are susceptible to damage. If damaged, the cord can cause an electric shock or short circuit. Ensure that the wiring position is not in the customer's passage way or the wiring has protective covering.
  • Page 17 IC18 GOOD IC20 GOOD IC22 GOOD IC09 GOOD IC10 GOOD IC11 GOOD IC12 GOOD PRESS TEST BUTTON TO EXIT ROM BOARD TEST [AIRLINE PILOTS IN XXXX] TYPE RESULT BYTE WORD IC22 32M ---- XXXX XXXX GOOD XXXX XXXX GOOD XXXX XXXX...
  • Page 18 (2) C.R.T. TEST In the TEST mode menu, selecting C.R.T. TEST allows the screen (on which the monitor is tested) to be displayed. Although the monitor adjustments have been made at the time of shipment from the factory, color deviation, etc., may occur due to the effects of geomagnetism, the location of the building’s steel frames and other game machines in the periphery.
  • Page 19 (3) INPUT TEST INPUT TEST Selecting the INPUT TEST on the game test mode menu screen carses the screen (on which each switch LANDING GEAR SWITCH and V.R. are tested) to be displayed. Press each switch. FLAP SWITCH If the display beside each switch indicates “ON,” the VIEW CHANGE BUTTON switch and wiring connections are satisfactory.

  • Page 20: Precautions To Be Heeded When Moving Machine

    5 . PRECATIONS TO BE HEEDED WHEN MOVING THE MACHINE When moving the machine, be sure to pull out the plug from the power supply. Moving the machine with the plug inserted can damage the power cord and cause a fire or electric shock. When moving the machine on the floor, retract the Adjusters and ensure that Casters make contact with the floor.

  • Page 21: Contents Of Game 18~20

    The following explanations apply in the event the product is functioning satisfactorily. Should there be any moves different from the following contents, some sort of faults may have occured. Immediately look into the cause of the fault and eliminate the cause thereof to ensure satisfactory operation. SEGA LOGO TITLE GAME MODE Returns to the beginning ♦...
  • Page 22 Press the START button to start. When the GAME MODE select screen appears, select TRAINING mode or FLIGHT mode. -Incline the CONTROL WHEEL left or right to select and press the START button to confirm the selection (hereafter, this method applies to any selection).
  • Page 23 <In the case FLIGHT MODE is selected:> -The FLIGHT COURSE select mode appears on the screen. Select one from among BEGINNER, INTERMEDIATE, and EXPERT. -The specific flight course of BEGINNER, INTERMEDIATE, and EXPERT corre- sponds to flight in the daytime, evening, and nighttime respectively.

  • Page 24: Explanation Of Test And Data Display 21~34

    7 . EXPLANATION OF TEST AND DATA DISPLAY By operating the switch unit, periodically perform the tests and data check. When installing the machine initially or collecting cash, or when the machine does not function correctly, perform checking in accordance with the explanations given in this section.

  • Page 25: Switch Unit And Coin Meter

    7 - 1 SWITCH UNIT AND COIN METER Never touch places other than those specified. Touching places not specified can cause electric shock and short circuit. Adjust to the optimum sound volume by considering the environmental requirements of the installation location. If the COIN METER and the game board are electrically disconnected, game play is not possible.

  • Page 26: System Test Mode 23~29

    7 - 2 SYSTEM TEST MODE •The contents of settings changed in the TEST mode are stored when the TEST mode is finished from EXIT in the MENU mode. If the power is turned off before the TEST mode is finished, the contents of the setting changes do not take effect. •Executing “BACKUP DATA CLEAR”...

  • Page 27: A C.r.t. Test

    A C.R.T. TEST 1) RGB COLOR ADJUSTMENT SCREEN In this screen, monitor color can be checked. C.R.T. TEST 1/2 Each of red, green, and blue is the darkest at the leftmost end, and becomes brighter towards the right-hand end in 31 gradiations. Monitor brightness is satisfactory if the white color bar is black at the left end and if it is white at the right end.

  • Page 28: B Coin Assignments 25~29

    B COIN ASSIGNMENTS The “COIN ASSIGNMENTS” mode permits you to set the start number of credits, as well as the basic numbers of coins and credits. This mode expresses “how many coins correspond to how many credits.” SETTING CHANGE PROCEDURE Setting changes cannot be stored unless the TEST BUTTON is pressed while the arrow is on EXIT.
  • Page 29 (C) MANUAL SETTING The Credit’s incremental increase settings as against a coin insertion are shown in further details than in (B) above (refer to Table 2). Also, note that when this MANUAL SETTING is performed, (B) COIN CREDIT setting becomes ineffective. MANUAL SETTING COIN ASSIGNMENTS MANUAL SETTING...
  • Page 30 Table 1: COIN/CREDIT SETTING (COIN CHUTE COMMON TYPE) SETTING FUNCTION OF CHUTE#1 SETTING #1 1 COIN 1 CREDIT SETTING #2 1 COIN 2 CREDITS SETTING #3 1 COIN 3 CREDITS SETTING #4 1 COIN 4 CREDITS SETTING #5 1 COIN 5 CREDITS SETTING #6 1 COIN...
  • Page 31 Table 2: MANUAL SETTING 1 COIN 1 CREDIT COIN TO CREDIT 2 COINS 1 CREDIT 3 COINS 1 CREDIT 4 COINS 1 CREDIT 5 COINS 1 CREDIT 6 COINS 1 CREDIT 7 COINS 1 CREDIT 8 COINS 1 CREDIT 9 COINS 1 CREDIT NO BONUS ADDER BONUS ADDER...
  • Page 32 (G) SEQUENCE SETTING Number of credits required for starting a game, etc. can be set. Each sequence can be set between 1 ~ 5 credit(s). COIN ASSIGNMENTS SEQUENCE SETTING SEQUENCE 1 2 CREDIT(S) SEQUENCE 2 1 CREDIT(S) SEQUENCE 3 1 CREDIT(S) SEQUENCE 4 1 CREDIT(S) SEQUENCE 5...

  • Page 33: Game Test Mode 30~34

    7 - 3 GAME TEST MODE MENU MODE AIRLINE PILOTS TEST MENU SYSTEM MENU INPUT TEST RAM TEST OUTPUT TEST JVS TEST SOUND TEST SOUND TEST C.R.T. TEST C.R.T. TEST GAME ASSIGNMENTS SYSTEM ASSIGNMENTS VOLUME SETTING COIN ASSIGNMENTS BOOKKEEP ING...

  • Page 34: A Input Test

    A. INPUT TEST Select INPUT TEST to have the screen shown below appear and to observe the status of each switch and the value of each V.R. on the Control Panel. In this mode, Periodically check the status of each switch and V.R.

  • Page 35: C Sound Test

    C. SOUND TEST This test mode allows each sound used in the game to be checked. SOUND TEST Press the SERVICE button to increase the number No. 0 sequentially, emitting the next sound to be tested. Press the TEST button to return to the TEST MENU. SELECT WITH SERVICE BUTTON PRESS TEST BUTTON TO EXIT D.

  • Page 36: E Game Assignments

    E. GAME ASSIGNMENTS Selecting the GAME ASSIGNMENTS in the MENU mode causes the present game settings to be displayed and allows game setting changes (game difficulty, etc.) to be made. After setting changes, be sure to exit from the TEST mode; the settings are not renewed until the TEST mode is exited.

  • Page 37: G Bookkeeping

    G. BOOKKEEPING Choosing BOOKKEEPING in the MENU mode displays the data of the present operating status on 2 pages. Press the TEST BUTTON to proceed to PAGE 2/2. Pressing the TEST BUTTON while the second page is displayed returns the screen to the MENU mode. BOOKKEEPING PAGE1/2 TOTAL TIME:...

  • Page 38: Control Mecha

    8. CONTROL MECHA Be sure to turn power off before performing work, and avoid touching undesignated places. Failure to do so can result in electric shock and short circuit accidents. Be careful so as not to damage wirings. Damaged wiring can cause electric shock and short circuit hazards.

  • Page 39: Adjusting The Volume

    8 - 2 ADJUSTING THE VOLUME Never touch places other than those specified. Touching unspecified places can cause electric shock and/or short circuit. After the replacement or adjustment of the VR, be sure to set the variable value of the VR in the test mode’s Volume Setting. The Volume Brackets can be moved by loosening 2 screws from each Bracket.

  • Page 40: Greasing

    8 - 4 GREASING Be sure to turn the power off first, before performing work, and avoid touching unspecified places. Failure to do so can cause electric shock and/or short circuit. Be sure to use the designated grease. Using undesignated grease can cause parts damage Do not apply greasing to undesignated places.

  • Page 41: Replacing The Switch Lever

    8 - 5 REPLACING THE SWITCH LEVER Before starting to work, ensure that the Power SW is OFF. Failure to observe this can cause electric shock/short circuit. Use care so as not to damage wirings. Damaged wiring can cause electric shock and short circuit hazards.

  • Page 42: Lever Unit 39~40

    9. LEVER UNIT In order to prevent electric shock and short circuit, be sure to turn off the power before performing work on the interior parts of the product. Be careful not to damage wiring. Damaged wiring can cause electric shock or short circuit.

  • Page 43: Replacing The Volume

    9 - 2 REPLACING THE VOLUME Be sure to turn the power off first, before performing work, and avoid touching unspecified places. Failure to do so can cause electric shock and/or short circuit. Remove the Volume Gear from the Volume to replace the Volume. After replacing the Volume, make adjustments as per 11-1 ADJUSTING THE VOLUME.

  • Page 44: Pedal Unit 41~42

    10. PEDAL UNIT In order to prevent electric shock and short circuit, be sure to turn off the power before performing work on the interior parts of the product. Be careful not to damage wiring. Damaged wiring can cause electric shock or short circuit.

  • Page 45: Replacing The Volume

    10 - 2 REPLACING THE VOLUME Be sure to turn the power off first, before performing work, and avoid touching unspecified places. Failure to do so can cause electric shock and/or short circuit. Remove the Volume Gear from the Volume to replace the Volume. After replacing the Volume, make adjustments as per 12-1 ADJUSTING THE VOLUME.

  • Page 46: Coin Selector

    11 . COIN SELECTOR HANDLING THE COIN JAM If the coin is not rejected when the REJECT BUTTON is pressed, open the coin chute door and open the selector gate. After removing the jammed coin, put a normal coin in and check to see that the selector correctly functions.
  • Page 47 OPTIONAL DOLLAR BILL ACCEPTOR THE COIN DOOR ASSEMBLY USED ON AIRLINE PILOTS STD TYPE COMES EQUIPPED TO ACCEPT A DOLLAR BILL ACCEPTOR. ALL NEEDED WIRING CONNECTIONS ARE CONVIENENTLY LOCATED INSIDE THE GAME FOR THIS APPLICATION. THE COIN DOOR CAN ACCCOMMODATE THE FOLLOWING...

  • Page 49: Monitor 46~48

    (plug) before starting work. Proceeding the work without following this instruction can cause electric shock of malfunctioning. Using the monitor by converting it without obtaining a prior permission is not allowed. SEGA shall not be liable for any malfunctioning and accident caused by said conversion.

  • Page 50: Cautions To Be Heeded When Cleaning

    For the purpose of static prevention, special coating is applied to the CRT face of this product. To protect the coating, pay attention to the following points. Damaging the coating film can cause electric shock to the customers. For the caution to be heeded when clearing, refer to the Section of Periodic inspection Table.

  • Page 51: Adjustment Method

    12 - 3 ADJUSTMENT METHOD Monitor adjustments are made at the time of shipment. Therefore, do not make further adjustments without a justifiable reason. Adjusting a monitor which contains high tension parts is dangerous work. Also, an erroneous adjustment can cause deviated synchro- nization and image fault, resulting in malfunction.

  • Page 52: Replacing The Fluorescent Lamp

    13. REPLACING THE FLUORESCENT LAMP When performing the work, be sure to turn power off. Working with power on can cause an electric shock or short circuit acci- dent. The Fluorescent Lamp, when it gets hot, can cause burns. Be very careful when replacing the Fluorescent Lamp.

  • Page 53: Periodic Inspection Table

    14. PERIODIC INSPECTION TABLE The items listed below require periodic checks and maintenance in order to retain the performance of this machine and ensure safe operation. Be sure to check once a year to see if Power Cords are damaged, the Plug is securley inserted, dust is accumulated between the Socket Outlet and the Power Plug, etc.

  • Page 54: Troubleshooting

    15. TROUBLESHOOTING Should trouble occur, first check wiring connections. PROBLEMS CAUSE COUNTERMEASURES When Main SW is The power is not on. Firmly insert the plug into the outlet. ON, there is no activation. Power supply/voltage is incorrect. Make sure that the power supply/voltage is correct.

  • Page 55: Game Board 52~53

    16. GAME BOARD In order to prevent an electrical shock, be sure to turn power off before performing work. Be careful so as not to damage wirings. Damaged wiring can cause an electric shock or short circuit accident. In this product, setting changes are made during the test mode. The Game BD need not be operated.

  • Page 56: Composition Of The Game Board

    16 - 2 COMPOSITION OF GAME BOARD Be sure to use the specified settings for the DIP SWes on the Filter Board. Failure to do so may cause irregularities or malfunctioning, such as unsatisfactory images displayed on the screen. ASSY CASE NAO USA (840-0005D-05) DIP SW SETTING In this product, be sure to set all of the DIP SWes to OFF.

  • Page 57: Design Related Parts 54~55

    17. DESIGN RELATED PARTS...
  • Page 58 SUB INSTR SH APC STD ENG APC-3110-A STICKER SEAT BACK APC-1551-A STICKER SIDE L APC-1571-A STICKER SIDE R 421-9749-02 STICKER SEGA LOGO BLOW WHITE APC-1501-A STICKER BASE L APC APC-1501-B STICKER BASE R APC APC-1511-A STICKER BASE LID 422-0751-91-01 PLAY INSTR SH APC STD ENG...

  • Page 59: Parts List 56~92

    18. PARTS LIST 1 TOP ASSY APC STD...
  • Page 60 1 TOP ASSY APC STD ITEM NO. PART NO. DESCRIPTION APC-10001 ASSY COCKPIT APC-0200 ASSY BILLBOARD STD APC-0300 ASSY COINCHUTE TOWER RAL-0006 BLIND CAP SDW-0005 AC COVER SDW-0006 AC LID SDW-0007 CONNECTOR COVER SDW-0008 WIRE COVER SDW-0009 TOWER COVER INY-0004 BACK LID INY DYN-0008 BACK LID B...
  • Page 61 2 ASSY BILLBOARD STD (APC-0200) ITEM NO. PART NO. DESCRIPTION APC-0201 BILLBOARD BASE APC-0202 BILLBOARD PLATE STD APC-0203 PLATE HOLDER APC-0204 CONNECTOR LID APC-0205 BOLT LID 000-T00408-OC M SCR TH CRM M4 X 8...
  • Page 62 3 ASSY COINCHUTE TOWER (APC-0300)
  • Page 63 3 ASSY COINCHUTE TOWER (APC-0300) ITEM NO. PART NO. DESCRIPTION APC-0301 COINCHUTE TOWER DRT-0301 COIN METER BRKT SDW-0360 SW UNIT DP-1167 TNG LKG 105-5172 CHUTE PLATE DOUBLE 253-5366 CASH BOX 421-7501-02 STICKER 6.3V 0.15A APC-0303 CONN PNL TOWER STD 220-5482-91-~ ASSY C.C 2DR ~ 220-5237-92-~ ASSY C.C 2DR ~...
  • Page 64 4 SW UNIT (SDW-0360) ITEM NO. PART NO. DESCRIPTION KR-1060 SW BRACKET 509-5028 SW PB 1M 220-5179 VOL CONT B-5K OHM 601-0042 KNOB 22MM...
  • Page 65 5 ASSY COCKPIT (APC-10001)
  • Page 66 5 ASSY COCKPIT (APC-10001) ITEM NO. PART NO. DESCRIPTION APC-1500 ASSY MAIN BASE APC-1550 ASSY MONITOR COVER L APC-1570 ASSY MONITOR COVER R APC-1600 ASSY SEAT STD APC-2200 PEDAL UNIT APC-20001 ASSY CTRL PNL SPG-1008 ROOF LID APC-1088 SIDE PNL L APC-1089 SIDE PNL R SDW-1023...
  • Page 67 6 ASSY MAIN BASE (APC-1500)
  • Page 68 6 ASSY MAIN BASE (APC-1500) ITEM NO. PART NO. DESCRIPTION APC-1520 ASSY BASE BOX APC-1530 AC UNIT APC-4500 ASSY MAIN BD STD APC-4600 ASSY PWR SPLY STD APC-1502 FOOT BASE 260-0011-02 AXIAL FLOW FAN AC100V 50-60HZ 000-P00425-W M SCR PH W/FS M4 X 25 068-441616 FLT WSHR 4.4-16 X 1.6 030-000616-SB...
  • Page 69 7 ASSY BASE BOX (APC-1520) ITEM NO. PART NO. DESCRIPTION APC-1501 MAIN BASE DYN-2004 LOCK TNG APC-1523 BASE LID BRKT APC-1510 ASSY BASE LID R APC-1522 FLOOR MAT APC-1521 BASE LID F DYN-2007X LID EDGE L DYN-2009X LID EDGE R 220-5575 CAM LOCK MASTER W/O KEY 000-T00512-OB...
  • Page 70 8 MAIN BASE (APC-1501)
  • Page 71 8 MAIN BASE (APC-1501) ITEM NO. PART NO. DESCRIPTION DYN-2002X-A MAIN BASE BLANK APC-1501-A STICKER BASE L APC APC-1501-B STICKER BASE R APC SDW-1103 BASE FOOT 601-5699X LEG ADJUSTER BOLT M16 X 75 601-5471 CASTER 030-000816-S HEX BLT W/S M8 X 16 050-H01600-OB HEX NUT BLK M16...
  • Page 72 9 ASSY BASE LID R (APC-1510) ITEM NO. PART NO. DESCRIPTION DYN-2011 LOCK ROD A DYN-2012 LOCK ROD B DYN-2013 LOCK ARM DYN-2014 ROD HOLDER APC-1511 BASE LID R 601-7551 LOCK HANDLE 045-C02520 COT PIN 2.5 X 20 031-000510-OB CRG BLT BLK M5 X 10 050-F00500 FLG NUT M5...
  • Page 73 10 AC UNIT (APC-1530) ITEM NO. PART NO. DESCRIPTION APC-1531 AC BRKT 214-0202 AC INLET PANEL TYPE 509-5453-91-V-B SW ROCKER J8 V-B...
  • Page 74 11 ASSY MAIN BD STD (APC-4500) ITEM NO. PART NO. DESCRIPTION APC-4501 WOODEN MAIN BASE STD 840-0005D-05 ASSY CASE NAO APC W/O JAL 837-13551-92 I/O CONTROL BD FOR JVS 400-5397 SW REGU FOR JVS 000-P00416-W M SCR PH W/FS M4 X 16 011-P00325 TAP SCR PH 3 X 25 011-T03512...
  • Page 75 12 ASSY PWR SPLY STD (APC-4600) ITEM NO. PART NO. DESCRIPTION APC-4601 WOODEN PWR SPLY BASE STD 560-5426-H XFMR 100-120V 100V 5.5A 838-11856CE-02 CONNECT BD W/FUSE 6.3A CE 601-10369 STEREO PWR AMP 47 000-P00416-W M SCR PH W/FS M4 X 16 011-P00325 TAP SCR PH 3 X 25 011-T03512...
  • Page 76 13 ASSY MONITOR COVER L (APC-1550) ITEM NO. PART NO. DESCRIPTION APC-1550 COVER PANEL L APC-1560 ASSY SPEAKER L DYN-1032 MASK BRKT 000-P00408-W M SCR PH W/FS M4 X 8...
  • Page 77 14 ASSY SPEAKER L (APC-1560) ITEM NO. PART NO. DESCRIPTION APC-1561 SPEAKER BRKT 130-5156 SPEAKER BOX 8OHM 20W 000-P00512-W M SCR PH W/FS M5 X 12...
  • Page 78 15 ASSY MONITOR COVER R (APC-1570) ITEM NO. PART NO. DESCRIPTION APC-1571 COVER PANEL R APC-1565 ASSY SPEAKER R DYN-1032 MASK BRKT 000-P00408-W M SCR PH W/FS M4 X 8...
  • Page 79 16 ASSY SPEAKER R (APC-1565) ITEM NO. PART NO. DESCRIPTION APC-1561 SPEAKER BRKT 130-5156 SPEAKER BOX 8OHM 20W M SCR PH W/FS M5 X 12 M SCR PH W/FS M5 X 12...
  • Page 80 17 ASSY SEAT STD (APC-1600)
  • Page 81 17 ASSY SEAT STD (APC-1600) ITEM NO. PART NO. DESCRIPTION APC-3101 SEAT BASE APC-3112 SEAT FRAME STD APC-3103 SEAT MOUNT TRAY STC-1612 PROTECT RUBBER APC-3105 SAFETY GUARD FRONT APC-3113 SAFETY GUARD REAR STD APC-3107 SAFETY GUARD SIDE APC-3110 SEAT REAR COVER STD DYN-2131 UPPER SEAT DYN-2132...
  • Page 82 18 PEDAL UNIT (APC-2200)
  • Page 83 18 PEDAL UNIT (APC-2200) ITEM NO. PART NO. DESCRIPTION APC-2201 PEDAL BASE APC-2202 STOPPER SHAFT APC-2203 STOPPER RUBBER APC-2204 MAIN PIPE APC-2205 APC-2206 PEDAL UPPER APC-2207 PEDAL LOWER APC-2208 PEDAL COVER APC-2209X PEDAL REAR L APC-2210X PEDAL REAR R APC-2211 ROSTA BRKT APC-2212 VOL BRKT...
  • Page 84 19 ASSY CTRL PNL (APC-20001)
  • Page 85 19 ASSY CTRL PNL (APC-20001) ITEM NO. PART NO. DESCRIPTION APC-2501 CTRL PNL BASE STD APC-2502-01 CTRL PNL COVER STD EXP APC-2000 ASSY CONTROL MECHA APC-2100 ASSY YOKE APC-2150 ASSY VIRTUAL BUTTON APC-3250 ASSY LEVER MECHA APC-1066 YOKE COVER APC-1078 STICKER CENTER MARK APC-2503 SHIFT COVER LOWER...
  • Page 86 20 ASSY CONTROL MECHA (APC-2000)
  • Page 87 20 ASSY CONTROL MECHA (APC-2000) ITEM NO. PART NO. DESCRIPTION APC-2050 ASSY SLIDE BASE APC-2030 ASSY CENTERING MECHA APC-2090 ASSY SHAFT GUIDE APC-2003 STOPPER RUBBER STROKE APC-2004 STOPPER SHAFT STROKE APC-2012 VR BRKT STROKE INSU APC-2006 CABLE BEAR BRKT APC-2007 STROKE DAMPER SHAFT 601-7088-91 GEAR 64...
  • Page 88 21 ASSY CENTERING MECHA (APC-2030) ITEM NO. PART NO. DESCRIPTION APC-2031 CENTERING BASE APC-2032 CENTERING GUIDE APC-2033 EXT SPRING APC-2034 SPRING SHAFT APC-2035 SPRING COLLAR INNER APC-2036 SPRING COLLAR OUTER APC-2037 MUTE RUBBER 000-P00408-W M SCR PH W/FS M4 X 8 000-P00310-W M SCR PH W/FS M3 X 10 250-5421...
  • Page 89 22 ASSY SLIDE BASE (APC-2050)
  • Page 90 22 ASSY SLIDE BASE (APC-2050) ITEM NO. PART NO. DESCRIPTION APC-2051 MAIN SHAFT APC-2052 INNER BASE APC-2053 HOUSING PLATE 30 APC-2054 HOUSING PLATE 20 APC-2055 STOPPER RUBBER ROLL APC-2056 STOPPER SHAFT ROLL APC-2058 SLIDE BRKT L APC-2059 SLIDE BRKT R 601-10575 RACK 601-7088-91...
  • Page 91 23 ASSY SHAFT GUIDE (APC-2090) ITEM NO. PART NO. DESCRIPTION APC-2091 GUIDE BUSH BRKT APC-2093 L BRKT 000P00408-W M SCR PH W/FS M4 X 8...
  • Page 92 24 ASSY YOKE (APC-2100) ITEM NO. PART NO. DESCRIPTION APC-2101 YOKE APC-2102 THUMB CAP APC-2103 TRIGGER CAP RCR-2151 HANDLE GRIP RIGHT RCR-2152 HANDLE GRIP LEFT GLC-2036 STOPPER 000-P00410-OB M SCR PH BLK M4 X 10 008-P00510-OB TMP PRF SCR PH BLK M5 X 10 000-P00208 M SCR PH M2 X 8 060-F00200...
  • Page 93 25 ASSY VIRTUAL BUTTON (APC-2150) ITEM NO. PART NO. DESCRIPTION APC-2151X VR BUTTON BRKT 171-6478B PC BD LIGHTING SWX5 212-5205-12 CONN JST M 12P RTA 509-5560-Y* PB SW W/L 6V 1L Y 509-5561-S** PB SW W/L 6V 5L S * HAPP Part No. 55-0006-25 available ** HAPP Part No.
  • Page 94 26 ASSY LEVER MECHA (APC-3250) ITEM NO. PART NO. DESCRIPTION APC-3251 LEVER GUIDE APC-3252 LEVER BRKT INNER APC-3253 LEVER BRKT OUTER APC-3254 LEVER SHAFT APC-3255 SHUTTER PLATE APC-3256 STOPPER RUBBER LEVER APC-3257 STOPPER SHAFT LEVER APC-3258 Z BRKT TTR-2009 GEAR HOLDER 80 601-6005 ADJUST GEAR 601-10571...
  • Page 95 27 ASSY SW PLATE STD (APC-1580) ITEM NO. PART NO. DESCRIPTION APC-1581 SW BSE STD 390-6640-GR LED BD-0811-12V GREEN 390-6640-RE LED BD-0811-12V RED 509-5910 ROCKER SW M-2012YG 509-5911-G SW LEVER AT-4157 GRAY 509-5911-R SW LEVER AT-4157 RED 280-5185-7 SPACER TUBE L=7 050-F00300 FLG NUT M3...
  • Page 96 VISIT OUR WEBSITE!

Table of Contents
