Mec Speed Level 84RT Series Operator's Manual page 37

84RT Series Speed Level™
Decals (continued)
91846
1
INSPECT MACHINE AND MAKE SURE THAT IT IS OPERATING PROPERLY,
THAT ALL NAME PLATE AND SAFETY AND CONTROL DECALS ARE IN PLACE
AND LEGIBLE, AND THAT THE MACHINE IS IN ACCORDANCE WITH THE
MANUFACTURER'S MAINTENANCE REQUIREMENTS CONTAINED IN THE
OPERATION AND MAINTENANCE MANUAL AND THE DAILY SAFETY CHECKLIST.
OPERATE MACHINE WITH EXTREME CAUTION. WATCH FOR OBSTRUCTIONS
WHICH MAY STRIKE PLATFORM, PERSONNEL, CONTROLS, OR MACHINE.
OPERATE CONTROLS SLOWLY FOR SMOOTH PLATFORM MOTION.
OTHER HAZARDS
FOR DRIVING WITH PLATFORM LOWERED:
1. DO NOT EXCEED PLATFORM LOAD CAPACITY.
DO NOT EXCEED MAXIMUM PLATFORM OR
2. DO NOT EXCEED MAXIMUM SIDE FORCE AND
EXTENSION LOAD LIMIT CAPACITY.
MAXIMUM NUMBER OF OCCUPANTS.
LOAD TO BE UNIFORMLY DISTRIBUTED.
3. DO NOT USE WITHOUT GUARD RAILS IN PLACE,
PLACE LOAD NEAR CENTER OF PLATFORM
AND ENTRY GATE PROPERLY SECURED.
WHEN POSSIBLE.
4. DO NOT USE IF WORK PLATFORM IS NOT WORKING
DO NOT DRIVE ON SIDE SLOPE IF PLATFORM PROPERLY OR IF ANY PART IS DAMAGED OR WORN.
IS OVER 5% OFF LEVEL.
5. DO NOT USE NEAR MOVING VEHICLES OR CRANES.
6. DO NOT STAND OR SIT ON GUARDRAILS,
DO NOT DRIVE UP OR DOWN A GRADE OF
ALL PERSONNEL SHALL ALWAYS MAINTAIN FIRM
OVER 40%.
FOOTING ON PLATFORM FLOOR.
7. DO NOT USE WHILE UNDER THE INFLUENCE OF
ALCOHOL OR DRUGS.
8. DO NOT OVERRIDE SAFETY DEVICES.
FOR DRIVING WITH PLATFORM ELEVATED:
9. DO NOT LEAVE MACHINE UNATTENDED WITH KEY
IN THE SWITCH.
DRIVE ONLY ON A SMOOTH, FIRM, AND PLANAR
10. DO NOT RAISE PLATFORM WHILE MACHINE IS ON
SURFACE FREE OF OBSTRUCTIONS.
A TRUCK, FORKLIFT, OR OTHER DEVICE OR VEHICLE.
11. DO NOT USE LADDER, SCAFFOLDING, OR OTHER
DO NOT EXCEED MAXIMUM PLATFORM OR
DEVICES TO INCREASE SIZE OR WORKING HEIGHT
EXTENSION LOAD CAPACITY.
OF PLATFORM.
12. DO NOT ENTER OR EXIT PLATFORM WHILE IN MOTION.
LOAD MUST BE UNIFORMLY DISTRIBUTED.
13. DO NOT RECHARGE BATTERIES NEAR
SPARKS OR OPEN FLAME, BATTERIES EMIT
IF TILT WARNING LIGHT ILLUMINATES OR
HIGHLY EXPLOSIVE HYDROGEN GAS.
TILT ALARM SOUNDS LOWER PLATFORM
AND RE-LEVEL 14. DO NOT PERFORM SERVICE ON THE MACHINE WITHOUT
PROPERLY SUPPORTING ELEVATING ASSEMBLY.
15. DO NOT ATTACH OVERHANGING LOADS OR
USE EXTREME CAUTION.
INCREASE PLATFORM SIZE.
IMPROPER OPERATION OF THIS MACHINE
COULD CAUSE DEATH OR SERIOUS INJURY.
8
91869
WARNING
SHEET LOADING GATE MUST BE IN LOCKED POSITION
BEFORE OPERATING FROM PLATFORM.
PLATFORM ENTRANCE MUST BE PROPERLY CLOSED AND
ALL GUARDRAILS PROPERLY IN PLACEAND SECURED
BEFORE OPERATING FROM PLATFORM.
FAILURE TO FOLLOW INSTRUCTIONS COULD CAUSE
DEATH, PERSONAL INJURY AND PROPERTY DAMAGE
CONTROL MODULE
12
91854: Dual Fuel 91855: Diesel
13 91848
PLATFORM CAPACITY
1500 LBs (680kg)
91848
90751
15
90267
16
8779
18
90732
19
WARNING
DO NOT POWERWASH OR
SPRAY ELECTRONIC
COMPONENTS OR
CONNECTORS.
MOISTURE MAY CAUSE
DAMAGE AND/OR
ERRATIC OPERATION
90732
91857rev2– February 2013
91845
2
YOU MUST NOT OPERATE
THIS MACHINE:
UNLESS YOU HAVE BEEN AUTHORIZED TO
USE AND TRAINED IN THE SAFE OPERATION
OF THIS MACHINE.
TRAINING INCLUDES COMPLETE KNOWLEDGE OF
THE SAFETY AND OPERATION INSTRUCTIONS
CONTAINED IN THE MANUFACTURERS MANUAL,
ANSI MANUAL OF RESPONSIBILITIES, YOUR
EMPLOYERS WORK RULES AND APPLICABLE
GOVERNMENTAL REGULATIONS.
AN UNAUTHORIZED AND UNTRAINED OPERATOR
SUBJECTS THEMSELF AND OTHERS TO
DEATH OR SERIOUS INJURY.
ELECTROCUTION HAZARD
THIS MACHINE IS NOT INSULATED
MAINTAIN SAFE CLEARANCE FROM ELECTRICAL
LINES AND APPARATUS. YOU MUST ALLOW FOR
MACHINE SWAY, ROCK OR SAG AND ELECTRICAL
LINES SWAYING.
THIS MACHINE DOES NOT PROVIDE PROTECTION
FROM CONTACT WITH OR PROXIMITY TO AN
ELECTRICALLY CHARGED CONDUCTOR.
YOU MUST MAINTAIN A CLEARANCE OF AT
LEAST TEN (10) FEET BETWEEN ANY PART
OF THIS MACHINE OR ITS LOAD AND ANY
ELECTRICAL LINE OR APPARATUS CARRYING UP
TO 50,000 VOLTS. ONE FOOT OF ADDITIONAL
CLEARANCE IS REQUIRED FOR EVERY
ADDITIONAL 30,000 VOLTS OR LESS.
DEATH OR SERIOUS INJURY
WILL RESULT FROM CONTACT
OR INADEQUATE CLEARANCE
91846
91847
9
WARNING
MAXIMUM PLATFORM CAPACITY - EVENLY DISTRIBUTED
1500 LBS
680 kg
5-PERSONS
91869
91853
14 9052
17
9378 (Diesel)
DIESEL
ONLY
9378
6872 (Dual Fuel)
GASOLINE
ONLY
6872
20 6948 (Dual Fuel)
WARNING
L.P.G.
1. NO SMOKING - WHILE CHANGING TANKS.
2. "MOUNT TANKS PROPERLY" USING HOLES IN COLLAR
FOR HORIZONTAL MOUNTING AND SLOT FOOTRINGS
FOR VERTICAL MOUNTING TO INSURE FULL USAGE.
3. OPEN VALVE SLOWLY SO THAT HOSE AND TANK
PRESSURE CAN EQUALIZE OR VALVE MAY SLUG.
4. CLOSE VALVE BEFORE DISCONNECTING AND USE UP
FUEL STILL IN LINE.
5. FOR PROPER USE OF THE L.P. SYSTEM, THE USE OF
FUEL MANUFACTURED TO NATURAL GAS PROCESSORS
ASSN. SPECIFICATIONS - "HD-5" - IS RECOMMENDED.
6948
PLATFORM
3
90733
TIP-OVER HAZARDS
DO NOT DRIVE NEAR DROP-OFFS,
HOLES, OPEN ELEVATOR SHAFTS,
AND LOADING DOCKS
5
90718
DO NOT ELEVATE PLATFORM ON
UNEVEN OR SOFT SURFACES
DO NOT DRIVE ONTO UNEVEN OR
SOFT SURFACES WHEN ELEVATED
DO NOT RAISE PLATFORM IN
WINDY OR GUSTY CONDITIONS
DEATH OR SERIOUS INJURY
WILL RESULT FROM IMPROPER
USE OF THIS EQUIPMENT
91845 7 91849
DISTANCE FROM GROUND TO LADDER WILL VARY WITH GROUND VARIATIONS.
10 8606
SIDE LOAD
250 LBS
1100 N
91847
POWER MODULE
21
6873
HYDRAULIC OIL
6873
CONTROL MODULE
AND
POWER MODULE
FRONT AND REAR
22 8502 (4 PLACES)
(not required for Foam Filled tires)
INFLATE TO TIRE
MANUFACTURER'S MAX.
SPECIFICATIONS
OR SEE
SERVICE MANUAL
8502
23
8519 (4 PLACES)
WARNING
REPLACE TIRES WITH MANUFACTURER'S
EQUIPMENT ONLY.
FAILURE TO USE MANUFACTURER'S
TIRES MAY CAUSE MACHINE INSTABILITY.
REFER TO MAINTENANCE MANUAL FOR
REPLACEMENT PART NUMBER.
8519
29 30
11026730 91553
11026730
(4 PLACES)
MAX. PLATFORM HEIGHT
THIS MACHINE HAS BEEN CONSTRUCTED IN ACCORDANCE WITH SECTION 4 OF ANSI A92.6-2006 COVERED BY US PAT. #5,476,050 & CANADIAN PAT. #2,115,870
4
7155
MANUALS INSIDE
LOCATE CONTROL BOX HERE
FOR NORMAL OPERATION OF THIS UNIT
7155
90733
INSIDE DOCUMENT CASE
(2 PLACES)
CHECK DISTANCE BEFORE LEAVING PLATFORM.
91849
OPTION
8605
11
CERTIFIED LANYARD
ANCHORAGE POINT
UPPER CONTROLS
91859
25
24 90729
27
91843
26
7156
7156
BOOM
28
91870
BASE
MFG. DATE MODEL NUMBER
MEC AERIAL PLATFORM SALES CORP.
XX/XX XXXXXX
ELECTRICAL VOLTAGE
MAX. PLATFORM CAPACITY INCLUDING PERSONS
XX VOLTS
XXX kg = X PERSONS + XXX kg EQUIPMENT
XXX kg = X PERSONS + XXX kg EQUIPMENT
MAX. MANUAL FORCE
XXX LBS
MAX. DRIVE HEIGHT MACHINE WEIGHT
XXX N
X X FT XXXX LBS
X.X m XXXX kg
MAX. GROUND
MAX. WIND SPEED PRESSURE PER WHEEL
X X FT X MPH X.X PSI
X.X m X m/s X.X kg/cm²
Decals
6
91850
91850
(6 PLACES)
8605
91859
91843
SERIAL NUMBER MODEL YEAR
XXXXXXXXX 20XX
MAX. HYDRAULIC
MAX. LOAD SYSTEM
PER WHEEL PRESSURE
XXX LBS XXXX PSI
XXX kg XXXX bar
91553
ART_3095 R1
