84RT Series Speed Level™

Deck Extension -- 2684 models only

91857rev2– February 2013
The deck will extend in intervals of 8 inches (20 cm) throughout the entire 48 inch (1.2m)
length of the deck extension. The extension handle hangs from the top rail at the left side of the
deck extension. The handle is used to push or pull the deck extension to the desired position.
To extend or retract the deck:
• Lift the handle to release the spring-loaded pin from the locked position.
• Push to extend or pull to retract the deck extension.
• Lower the handle enough for the spring-loaded pin to engage and continue to push
or pull the deck extension until the pin locks into position.
Do not stand on the deck extension while extending or retracting it.
Check that the deck extension is locked in place before using the machine or transporting the
machine by vehicle.
Operating Instructions
Page 17
