Mec Speed Level 84RT Series Operator's Manual page 17

84RT Series Speed Level™
ART_3228
ART_3227
ART_3227
91857rev2– February 2013
Drive Torque (Speed Control)
Drive speed is selectable until the platform is elevated above 10 Feet (3 m). When the platform
is elevated the machine defaults to MID RANGE and the switch is locked-out (non
functioning).
• HIGH SPEED: allows speeds up to 3 m.p.h. (4.8 km/h).
• MID RANGE: allows speeds up to 0.4 m.p.h. (0.6 km/h).
• HIGH TORQUE: use to drive up or down a slope that is too steep for normal speed.
Drive Forward
• Place the MODE SELECT switch in the DRIVE position.
• Squeeze the enable bar and move the joystick away from you.
Test Operation
• Drive speed is proportional and is dependent on the movement of the
joystick.
• Releasing the enable bar or returning the joystick to the center position will
stop drive.
• Pressing the EMERGENCY STOP switch will stop drive.
Drive Reverse
• Place the MODE SELECT switch in the DRIVE position.
• Squeeze the enable bar and move the joystick toward you.
Test Operation
• Drive speed is proportional and is dependent on the movement of the
joystick.
• Releasing the enable bar or returning the joystick to the center position will
stop drive.
• Pressing the EMERGENCY STOP switch will stop drive.
Brake
• For parking, the brake is automatically applied when the joystick is positioned in the
neutral (center) position.
Operating Instructions
Page 15
