84RT Series Speed Level™

Serial Plate Location

ART_3094 R1
MFG DATE
X X / X X
YEAR
MONTH
ART_2377
MODEL NUMBER
30 8 4 RT
Rough
Terrain
Machine width
in INCHES
Max. platform height
in FEET
ART_3087
91857rev2– February 2013
The serial plate is attached to the machine at the time of manufacture. Important
information about the machine is recorded on the serial plate.

Serial Plate Description

Serial Plate Item Information Defined
MFG DATE. Month / Year of manufacture
MODEL NUMBER. Identifies the machine.
SERIAL NUMBER. Identifies a machine with reference to its original owner. Refer to the
number when requesting information or ordering parts.
MAX. WIND SPEED. The maximum safe wind speed at which the machine can be elevated.
MAX. PLATFORM CAPACITY INCLUDING PERSONS. The maximum safe load (persons
+ equipment) which can be evenly distributed on the platform at any elevation
MAX. ALLOWABLE MANUAL FORCE. The maximum safe force that the occupant can
exert laterally on an object outside the platform.
MAX. PLATFORM HEIGHT. The maximum attainable height measured from level ground
surface to platform floor.
MAX. DRIVE HEIGHT. The maximum safe platform height at which the machine can be
driven.
MAX. LOAD PER WHEEL. The maximum safe weight applied to each wheel. Calculated
with all available options installed.
Fw = 30% (Wm + Wc + Wopt)
MAX. GROUND PRESSURE PER WHEEL. The amount of pressure exerted on the surface
at each wheel. Calculated with all available options installed.
Pmax = 30% (Wm + Wc + Wopt) / Contact Area
STANDARD MACHINE WEIGHT. The weight of the machine with no options.
OPTIONAL EQUIPMENT ADDS TO STANDARD MACHINE WEIGHT. The weight of
installed optional equipment.
