RAID canister LEDs
Figure 1-13
1 1
1
RAID canister LEDs
Table 1-12
Number
1
2
3
4
5
6
7
8
9
The Expansion Storage Shelf also contains two fans, on either side, and two power
supplies, in the top and the bottom slots. The power supplies should be connected
to the Power Distribution Units (PDU), which must be connected to an external
240V power supply. The two center slots contain expansion canisters, one of which
must always function. The Expansion Storage Shelf must be attached to a Primary
Storage Shelf by SAS cables, plugged into the expansion canisters.
About the NetBackup 5330 Appliance storage capacity
1
4 5 6 7 8
9
Description
Data link activity
SAS expansion fault
SAS expansion active
Battery service action
required
Battery charging
RAID service system action
allowed
RAID service system action
required
Cache active
Seven-segment display LEDs
for system ID
NetBackup 5330 Appliance overview
2 3
1 1 1 1
Color
Green
Amber
Green
Amber
Green
Blue
Amber
Green
Displays '99'
