About the NetBackup 5330 Appliance Primary Storage Shelf and
Expansion Storage Shelf rear panels
Primary Storage Shelf and Expansion Storage Shelf front panel LED
Table 1-10
definitions (continued)
Number
5
As mentioned, each drawer in a storage shelf contains slots for 12 disks. The slots
are numbered as shown in the following diagram.
Drawer disk layout
Figure 1-11
The NetBackup 5330 Appliance Primary Storage Shelf and the Expansion Storage
Shelf includes two power cords that should be plugged into the appropriate external
power source within a rack. When connecting power cables, wear an ESD-preventive
wrist strap to prevent equipment damage.
The rear panel of both disk systems contains three types of canisters:
RAID or Expansion canisters
■
AC power canisters (220VAC)
■
Fan canisters
■
About the NetBackup 5330 Appliance storage capacity
Definition
Service Action Required LED
NetBackup 5330 Appliance overview
Color
Amber
