About the NetBackup 5330 server disk configuration

NetBackup 5330 Appliance system features (continued)
Table 1-1
Feature
RAID levels
Fibre Channel support
Rear panel ports
See "About the NetBackup 5330 server disk configuration"
See "About NetBackup 5330 server disk drive LEDs"
See "About the NetBackup 5330 server control panel"
See "About the NetBackup 5330 server rear panel"
See "About NetBackup 5330 server PCIe slot configurations"
See "NetBackup 5330 Appliance Ethernet port configurations"
See "About the dual-port 8 GB Fibre Channel Host Bus Adapter (FC HBA)"
on page 17.
See "About the dual-port 10GB Ethernet card"
The NetBackup 5330 server contains eight 3TB SAS disks, which can be accessed
from the server's front panel. An embedded RAID controller on the server's
mainboard is used to configure four of the eight disks into two RAID1 mirrored
volumes. These volumes are labeled Volume 0 and Volume 1. The disks that are
located in slot 0 and slot 1 are configured as the RAID1, VOLUME 0 device, while
NetBackup 5330 Appliance overview
About the NetBackup 5330 Appliance
Description
RAID1 (striping and mirroring) and RAID6 (block level
striping with double distributed parity) are used as follows:
NetBackup 5330 server system disks: RAID1
■
Storage shelf data storage disks: RAID6
■
The NetBackup 5330 server can be ordered with two, three,
five, or six Fibre Channel (FC) HBA cards already installed.
Each card includes two standard Fibre Channel ports. If
less than six FC HBA cards are ordered, a 10Gb Ethernet
card with two standard ports can be ordered. The server
uses the QLE2562, a QLogic 8Gb PCIe dual port adapter.
One 1 Gb/s IPMI remote network port
One VGA port
Four 1GE network ports, with an RJ-45 connector, and link
and activity LEDs. Two of the ports are reserved for private
networks.
Two 10 GE network ports, with Small Form-factor Pluggable
(SFP) modules, and link and activity LEDs.
on page 18.
on page 10.
on page 11.
on page 12.
on page 13.
on page 15.
on page 16.
