12 disk drives. The front panels of both systems are physically and functionally the
same, as seen in the following diagram.
Primary Storage Shelf and Expansion Storage Shelf front panel
Figure 1-9
The following table shows the front panel LEDs in detail.
Disk system front panel LEDs
Figure 1-10
1
2
3
4
5
The following table describes LEDs available on the disk system front panel.
Primary Storage Shelf and Expansion Storage Shelf front panel LED
Table 1-10
definitions
Number
1
2
3
4
About the NetBackup 5330 Appliance storage capacity
1
2
3
4
5
Definition
Power LED
Standby Power LED
Locate LED
Over-temperature LED
NetBackup 5330 Appliance overview
Color
Green
Green
White
Amber
