  • Page 1 NetBackup 5330 Appliance Product Description Guide Release 2.6.1...
  • Page 2 Copyright © 2014 Symantec Corporation. All rights reserved. Symantec, the Symantec Logo, the Checkmark Logo, NetBackup, and Veritas are trademarks or registered trademarks of Symantec Corporation or its affiliates in the U.S. and other countries. Other names may be trademarks of their respective owners.
  • Page 3 Symantec Corporation 350 Ellis Street Mountain View, CA 94043 http://www.symantec.com Printed in the United States of America. 10 9 8 7 6 5 4 3 2 1...

  • Page 4: Technical Support

    The Technical Support group also creates content for our online Knowledge Base. The Technical Support group works collaboratively with the other functional areas within Symantec to answer your questions in a timely fashion. For example, the Technical Support group works with Product Engineering and Symantec Security Response to provide alerting services and virus definition updates.
  • Page 5 ■ Recent software configuration changes and network changes ■ Licensing and registration If your Symantec product requires registration or a license key, access our technical support Web page at the following URL: www.symantec.com/business/support/ Customer service Customer service information is available at the following URL: www.symantec.com/business/support/...
  • Page 6 Support agreement resources If you want to contact Symantec regarding an existing support agreement, please contact the support agreement administration team for your region as follows: Asia-Pacific and Japan customercare_apac@symantec.com Europe, Middle-East, and Africa semea@symantec.com North America and Latin America...

  • Page 7: Table Of Contents

    NetBackup 5330 Appliance overview ....... 8 About the NetBackup 5330 Appliance ..........8 About the NetBackup 5330 server disk configuration ..... 10 About the NetBackup 5330 server control panel ......12 About the NetBackup 5330 server rear panel ....... 13 About NetBackup 5330 server PCIe slot configurations ....

  • Page 8: Netbackup 5330 Appliance Overview

    About the NetBackup 5330 Appliance The NetBackup 5330 Appliance is a hardware and software storage system that scales to 229TB of usable backup capacity. It consists of a 2U NetBackup 5330 server and one attached 4U Symantec Primary Storage Shelf. For additional storage capacity, an optional 4U Expansion Storage Shelf can be added.
  • Page 9 Primary Storage Shelf, or a Primary Storage Shelf and an optional Expansion Storage Shelf. A NetBackup 5330 server that is paired with a Primary Storage Shelf provides usable storage capacity of 114.6 TB. When the server is paired with both the Primary Storage Shelf and the optional Expansion Storage Shelf, usable storage capacity increases to 229.2 TB.

  • Page 10: About The Netbackup 5330 Server Disk Configuration

    18. About the NetBackup 5330 server disk configuration The NetBackup 5330 server contains eight 3TB SAS disks, which can be accessed from the server's front panel. An embedded RAID controller on the server's mainboard is used to configure four of the eight disks into two RAID1 mirrored volumes.
  • Page 11 About the NetBackup 5330 Appliance the disks in slot 3 and slot 4 are configured as the RAID1, VOLUME 1 device. VOLUME 0 contains the NetBackup 5330 server operating system and the NetBackup application. The disks in slots 3 and 4 are configured as the RAID 1, VOLUME 1 device.

  • Page 12: About The Netbackup 5330 Server Control Panel

    Power on and drive spinning LED blinks About the NetBackup 5330 server control panel The front panel of the NetBackup 5330 server includes a small panel that is attached to the right side of the device. System information is shown on this panel.

  • Page 13: About The Netbackup 5330 Server Rear Panel

    NIC1/eth0 activity LED (for public use) NIC2/eth1 activity LED (for public use) Status LED About the NetBackup 5330 server rear panel The rear panel of a NetBackup 5330 server has several access ports and other features, which are displayed in the following diagram and table.
  • Page 14 NetBackup 5330 Appliance overview About the NetBackup 5330 Appliance NetBackup 5330 server rear panel access ports and features Figure 1-4 NetBackup 5330 server port functions Table 1-5 Number Function Power Supply Modules #1, #2 (120/220VAC) NIC1/eth0 and NIC2/eth1. NIC1/eth0 is reserved for use during the initial configuration of the appliance.

  • Page 15: About Netbackup 5330 Server Pcie Slot Configurations

    15. About NetBackup 5330 server PCIe slot configurations The rear panel of the NetBackup 5330 server contains six PCIe slots that are numbered 1 to 6. Slots 1, 2, and 3 are located in PCIe Riser Assembly 2. Slots 4, 5, and 6 are located in PCIe Riser Assembly 1.

  • Page 16: Netbackup 5330 Appliance Ethernet Port Configurations

    16. NetBackup 5330 Appliance Ethernet port configurations The rear panel of the NetBackup 5330 Appliance contains six PCIe slots, which are populated according to five different supported configurations. The PCIe slot configuration determines the number of Ethernet ports that are available on your appliance.

  • Page 17: About The Dual-Port 8 Gb Fibre Channel Host Bus Adapter (Fc Hba)

    PCIe slots. The number of ports depends on the PCIe slot configuration of your appliance. Table 1-7 shows the additional available Ethernet ports for each PCIe slot configuration. NetBackup 5330 Appliance PCIe Ethernet port configurations Table 1-7 Model Slot and Ethernet port number Slot 2: eth8 (right), eth9 (left) ■...

  • Page 18: About The Dual-Port 10Gb Ethernet Card

    (non-operating, non-condensing) About the dual-port 10GB Ethernet card The 10Gb Ethernet card is available with the NetBackup 5330 Appliance. The card can be installed in the PCI Riser Assembly in addition to Fibre Channel cards. Dual-port 10GB Ethernet card specifications...

  • Page 19: About The Netbackup 5330 Appliance Primary Storage Shelf And Expansion Storage Shelf Front Panel

    About the NetBackup 5330 Appliance Primary Storage Shelf and Expansion Storage Shelf front panel The NetBackup 5330 Appliance Primary Storage Shelf and Expansion Storage Shelf each contain 60 SAS hard disk drives. The front panel of the Primary Storage Shelf and Expansion Storage Shelf contain five drawers. The drawers are numbered...
  • Page 20 NetBackup 5330 Appliance overview About the NetBackup 5330 Appliance storage capacity 12 disk drives. The front panels of both systems are physically and functionally the same, as seen in the following diagram. Primary Storage Shelf and Expansion Storage Shelf front panel Figure 1-9 The following table shows the front panel LEDs in detail.

  • Page 21: About The Netbackup 5330 Appliance Primary Storage Shelf And Expansion Storage Shelf Rear Panels

    About the NetBackup 5330 Appliance Primary Storage Shelf and Expansion Storage Shelf rear panels The NetBackup 5330 Appliance Primary Storage Shelf and the Expansion Storage Shelf includes two power cords that should be plugged into the appropriate external power source within a rack. When connecting power cables, wear an ESD-preventive wrist strap to prevent equipment damage.
  • Page 22 The RAID canisters are attached to the NetBackup 5330 Appliance with fiber optic cables. The device must have at least one functioning RAID canister, one functioning power supply, and one functioning fan.
  • Page 23 NetBackup 5330 Appliance overview About the NetBackup 5330 Appliance storage capacity RAID canister LEDs Figure 1-13 4 5 6 7 8 RAID canister LEDs Table 1-12 Number Description Color Data link activity Green SAS expansion fault Amber SAS expansion active...
  • Page 24 NetBackup 5330 Appliance overview About the NetBackup 5330 Appliance storage capacity Expansion Storage Shelf rear panel Figure 1-14 Expansion Storage Shelf rear panel components Table 1-13 Number Description Fan canisters 2 and 5 Power canisters 3 and 4 Expansion canisters The following diagram shows the LEDs in the Expansion Storage Shelf canister, along with the SAS ports.
  • Page 25 NetBackup 5330 Appliance overview About the NetBackup 5330 Appliance storage capacity Expansion Storage Shelf rear panel features (continued) Table 1-14 Number Description LED Display Data Link LED Green SAS port Link fault LED Amber Data Link LED Green SAS port...
  • Page 26 NetBackup 5330 Appliance overview About the NetBackup 5330 Appliance storage capacity Comparison of the Primary Storage Shelf and Extension Storage Figure 1-15 Shelf canisters Primary Storage Shelf Expansion Storage Shelf...

  • Page 27: About Best Practices For Rack Installation

    Be aware of the depth of the guide rails and the devices. Ensure that the distance ■ between cabinet posts accommodates the rails and devices. The rack rails that are provided for the Symantec Storage Shelf are extensible ■ to 36” (914mm). This distance is the maximum depth that is allowed between...
  • Page 28 NetBackup 5330 Appliance overview About best practices for rack installation the rails and the appliance cannot be properly installed. The width of the storage shelf is 19” (482.6mm). If your rack dimensions do not conform to these requirements contact Symantec Technical Support.

  • Page 29: Netbackup 5330 Appliance Cables

    Chapter NetBackup 5330 Appliance cables This chapter includes the following topics: Power cables ■ Network cable ■ Multi-Mode fibre cable ■ SAS cable ■ Power cables Each AC power module of the appliance and of the storage device is configured with one AC power cable.

  • Page 30: Network Cable

    A power cable includes live line, neutral line, and grounding lines. Network cable The NetBackup 5330 Appliance communicates with the outside through an Ethernet network cable. One end of the network cable connects to the management network port or service network port of the appliance. The other end of the cable connects to the network switch or an external gateway.

  • Page 31: Multi-Mode Fibre Cable

    Figure 2-2 Multi-Mode fibre cable The NetBackup 5330 Appliance communicates with the fiber channel switch through a multi-mode fibre cable. One end of the multi-mode fibre cable connects to the 10GE service network port or the fibre channel port. The other end of the cable connects to the fiber channel switch or other devices.

  • Page 32: Sas Cable

    ■ SAS cable A SAS cable has a SAS connector on both ends. Two SAS cables ship with each Expansion Storage Shelf. SAS cable Figure 2-4 Refer to NetBackup 5330 Appliance and storage shelf connection sections as needed for details.

  • Page 33: Technical Specifications, Standards, And Compliance Information

    NetBackup 5330 Appliance system technical specifications Note: The maximum weight of the NetBackup 5330 Appliance includes the eight disk drive modules, eight disk drive carriers, and two power modules. Note: The maximum weight of the storage shelves includes 60 disk drive slots, two power canisters, and two fan canisters.
  • Page 34 (23°C +/- 2) System Cooling Requirement 460 watts maximum – 1570 BTU/hour 750 watts maximum – 2559 BTU/hour The technical specifications for the NetBackup 5330 Appliance Primary Storage Shelf and for the NetBackup 5330 Appliance Expansion Storage Shelf are as follows.
  • Page 35 Technical specifications, standards, and compliance information NetBackup 5330 Appliance system technical specifications Primary Storage Shelf and Expansion Storage Shelf technical Table A-2 specifications Parameter Description Rack information Weight Approximately 105.2 kg (232 lb) with the 60 disk drives installed Approximately 80 kg (176 lb) without the disk...

  • Page 36: Environmental Specifications

    Sound levels Sound power (standby operation): 6.5 bels Sound power (normal operation): 6.8 bels Sound pressure: 68 dB Environmental specifications The following table lists the requirements for the NetBackup 5330 Appliance and the storage shelves. Environmental specifications Table A-3 Component...

  • Page 37: Protocol Standards

    < 72 A-weighted decibel This value reflects the maximum noise of the appliance when the ambient temperature is 25°C. Protocol standards The following table provides standards with which the NetBackup 5330 Appliance and storage shelves comply. Standards compliance Table A-4 Standard Version IPMI 2.0...

  • Page 38: Index

    15 fibre channel host bus adapter 17 system features 10 system memory configuration 9 appliance server NetBackup 5330 Appliance technical specifications 33 disk drive layout 10 PCIe options 15 slot assignments and RAID disk assignments 11 PCIe options 15...
  • Page 39 Index rack installation best practices 27 RAID disk assignments appliance server 11 regulatory, compliance, and certification information 37 slot assignments appliance server 11 specifications environmental 36 standards protocol 37 storage shelf drawer disk layout 21 system features 10...
