About the dual-port 8 GB Fibre Channel Host Bus Adapter (FC HBA)

Additional ports are located in the 10-Gb Ethernet network interface cards that are
installed in the PCIe slots. The number of ports depends on the PCIe slot
configuration of your appliance.
Table 1-7 shows the additional available Ethernet ports for each PCIe slot
configuration.
NetBackup 5330 Appliance PCIe Ethernet port configurations
Table 1-7
Model
A
(four 10-Gb Ethernet cards)
B
(three 10-Gb Ethernet cards)
C
(two 10-Gb Ethernet cards)
D
(one 10-Gb Ethernet card)
E
(no 10-Gb Ethernet cards)
The Fiber Channel (FC) host bus adapter ports are used to connect the appliance
to a Primary Storage Shelf, along with clients and other devices for Fibre Transport
data transfer.
Dual-port 8 GB Fibre Channel Host Bus Adapter specifications
Table 1-8
Item
Dimensions
Power consumption
Operating temperature
About the NetBackup 5330 Appliance
Slot and Ethernet port number
Slot 2: eth8 (right), eth9 (left)
■
Slot 3: eth6 (right), eth7 (left)
■
Slot 5: eth10 (right), eth11 (left)
■
Slot 6: eth12 (right), eth13 (left)
■
Slot 2: eth8 (right), eth9 (left)
■
Slot 3: eth6 (right), eth7 (left)
■
Slot 5: eth10 (right), eth11 (left)
■
Slot 2: eth8 (right), eth9 (left)
■
Slot 3: eth6 (right), eth7 (left)
■
Slot 3: eth6 (right), eth7 (left)
■
N/A
Description
2.54 in x 6.6 in (6.4516 cm to 16.764 cm)
(low-profile)
Typical: 6.2 watts at 0°C to 55°C (32°F to
131°F)
0°C to 55°C
