ETC ArcSystem Pro One-Cell Series Installation Manual page 24

ETC Installation Guide
Pro One-Cell
ARC-TX1
DMX512
DMX512 from
lighting console
Note:
TX1, you must use the ArcSystem comissioning tool software to add DMX fixtures.
RDM Values
Manufacturer ID: 0x6574 (Electronic Theatre Controls)
Model IDs
Product Type
ArcSystem Pro One-Cell
or ArcSystem Pro One-Cell Small
ArcSystem Pro One-Cell High Output
ArcSystem Pro One-Cell Micro
ArcSystem D4 Drivers
Pro One-Cell
ArcSystem wireless
luminaires
DMX512
ArcSystem wired
DMX luminaires
By default the TX1 DMX output is disabled. If you require DMX output from the
Third party
DMX devices
Description
D1 Driver
D1 Emergency Driver
D1 High Output Driver
D1 High Output Emergency Driver
D2 Driver
D2 Emergency Driver
D4 Constant Current Driver
D4 Constant Voltage Driver
D4 Constant Current Emergency Driver
D4 Constant Voltage Emergency Driver
Page 24 of 29
Model ID
0x1201
0x1301
0x1202
0x1302
0x1203
0x1303
0x1204
0x1205
0x1304
0x1305
ETC
